178 Northeastern Naturalist Vol. 16, Special Issue 5
Soil and Vegetation Differences from Peridotite to
Serpentinite
Earl B. Alexander*
Abstract - Pedologists and ecologists generally consider peridotite and serpentinite
together as common serpentine soils or substrates. A detailed survey in the Klamath
Mountains, CA, with separate soil map units on peridotite and serpentinite revealed
appreciable differences in geomorphic and pedologic features between these types
of ultramafic rocks. Slopes tend to be steeper on peridotite and the soils redder. More
Alfisols (Luvisols) were found on peridotite, and more Mollisols (Phaeozems) on serpentinite.
Very shallow soils (7% of the area), which are mostly Mollisols and Entisols
(Leptosols), are more common on serpentinite. Barrens are commonly fragmental
colluvium (talus) on peridotite and erodible, slightly to moderately stony summits
and slopes on serpentinite. The most obvious vegetation differences related to parent
material are on very shallow and shallow soils, with more coniferous trees (Pinus jeffreyi
[Jeffrey Pine] > Calocedrus decurrens [Incense Cedar] > Pseudotsuga menziesii
[Douglas Fir]) and Quercus durata (Leather Oak) on peridotite, and more Ceanothus
cuneatus (Buckbrush) and Vulpia microstachys (Annual Fescue) on serpentinite soils.
Introduction
Pedologists and ecologists generally consider peridotite and serpentinite
together as common serpentine soils or substrates (Brooks 1987, Kruckeberg
1984). This approach is easy to understand from a botanical perspective,
because there are few obvious vegetation differences from peridotite to
serpentinite. Topographic and soil differences are more obvious, but not so
obvious that they are perceived in casual observations.
Peridotite is a precursor of serpentinite. Serpentinite is produced by the
addition of water to peridotite in a metamorphic process called serpentinization.
The complete alteration of peridotite to serpentinite requires the addition
of about 13 or 14% water. Generally, calcium and silica are lost, but otherwise
the chemical composition is seldom changed in the metamorphosis (Coleman
1971). The mineralogy, however, is almost completely altered from olivine
and pyroxenes in peridotite to serpentine and accessory magnetite in serpentinite.
Generally, only chromite remains unaltered from the complete serpentinization
of peridotite (Coleman 1971).
A 33% expansion during serpentinization, from heavy peridotite (3.2–3.3
Mg/m3) to light serpentinite (2.4–2.6 Mg/m3), is commonly accompanied by
extensive fracturing and shearing. Consequently, most serpentinite breaks
into smaller blocks than does peridotite. The shearing commonly smooths
and polishes fracture surfaces in serpentinite, reducing its shear strength and
*Soils and Geoecology, 1714 Kasba Street, Concord CA 94518, USA; alexandereb@
att.net.
Soil and Biota of Serpentine: A World View
2009 Northeastern Naturalist 16(Special Issue 5):178–192
2009 E.B. Alexander 179
making it more susceptible than peridotite to mass failure. With these profound
structural differences, we might expect to find differences in peridotite
and serpentinite landscape topographies.
Mineralogy is very important in weathering and soil formation. Olivine
and the orthorhombic pyroxenes in harzburgite, the most common variety of
peridotite in the Rattlesnake Creek terrane (RCT), are more readily weatherable
than serpentine. Serpentinite formed from dunite (nearly all olivine),
however, contains much brucite, which is even more readily weathered than
olivine (Alexander 2004). Dunite is not extensive in the RCT. Even though
the parent material mineralogy is quite different, soils on peridotite and serpentinite
are commonly considered to be similar. The same soils are mapped
on both peridotite and on serpentinite in soil surveys of Washington, Oregon,
and California (e.g., Lanspa 1993). Perhaps because of their lack of economic
importance, serpentine soils have not been investigated intensively.
Soil differences from peridotite to serpentinite were recognized only in
detailed soil survey. Detailed soil survey is generally for agriculture; nearly
all serpentine soils in North America are in hilly or mountainous areas where
agriculture is seldom practiced because the slopes are steep and serpentine
soil chemistry limits plant productivity. A detailed soil survey in which
peridotite and serpentinite were separated in mapping revealed appreciable
differences in geomorphic and pedologic features between these two types of
ultramafic rocks. These differences may have been observed before, but they
were not recognized in reports from previous soil surveys. Nor have botanists
reported vegetation differences between serpentinite and peridotite,
but some obvious vegetation differences and trends from peridotite to serpentinite
were observed in data from sites described for soil and landscape
characterization in the RCT (Alexander 2003).
My objective was to indicate major differences between peridotite and
serpentinite soils and vegetation recognized in a detailed soil survey area of
the RCT in the Klamath Mountains (Fig. 1). Pedologists generally do not
considered soil differences from periditite to serpentinite, and because most
plant distributions are similar on peridotite and serpentinite, the possible
differences are generally not considered by ecologists (Kruckeberg 1984).
Although soil mapping in the RCT was not designed to obtain a definitive
comparison of vegetation on peridotite and serpentinite soils, data from it
serve as a basis for retrospective evaluation of the differences.
Field-site Description
The area of detailed serpentine soil survey is in the southern exposure
of the RCT (Fig. 1). This is an allochthonous terrane annexed to the North
American continent during the Mesozoic era. It contains serpentinized harzburgite,
gabbro, basalt, graywacke (clastic marine sediments), chert, and
minor limestone. Some small granitic plutons intruded the terrane after it
was accreted to the continent (Wright and Wyld 1994).
The RCT extends about 120 km, from the southeast corner to the western
edge of the Klamath Mountains in a strip that is about 6 to 16 km wide. It is
180 Northeastern Naturalist Vol. 16, Special Issue 5
in mountainous terrain, with some small valleys. A peneplain that extended
across the Klamath Mountains during the Tertiary (Diller 1902) is no longer
evident in the RCT, unless it is represented by the small summit flats of Red
Mountain (1718 m asl) on the southeast portion of RCT and Sugar Pine
Mountain (1202 m asl) on the northwest.
The current climate is temperate with warm, dry summers and cold, wet
winters. Mean annual temperatures range from 8 to 16 °C. Mean annual precipitation
is mostly in the range from 100 to 150 cm, with extremes of about
75 cm on the southeast portion of RCT and 200 cm on the northwest. Soil
temperature regimes are mesic and thermic, mostly mesic, with minor frigid
regimes; and soil moisture regimes are xeric (Soil Survey Staff 1999).
The vegetation is mostly open conifer forest (Fig. 2) and chaparral. Tree,
shrub, and herb species distributions differ substantially from hotter and drier
low elevations to cooler and wetter high elevations. Tree and grass species
distributions, however, are somewhat similar from southeast to northwest at
the intermediate elevations in the RCT.
Methods
A detailed soil survey of the approximately 12,000 ha of serpentine in the
southern exposure of the RCT was conducted with stereo pairs of 1:16,000
aerial photographs (Alexander 2003). The minimum delineation was about
one hectare, and most of the map polygons were observed on the ground.
Soils chosen to represent those of the map units were described to bedrock,
Figure 1. Location of the
southern exposure of the
Rattlesnake Creek terrane
in the Klamath Mountains.
2009 E.B. Alexander 181
or to about 150 cm depth, at 208 sites: 73 on peridotite, 108 on serpentinite,
14 on other rocks associated with serpentine, and 13 on large landslides.
Soils were classified according to Soil Taxonomy (Soil Survey Staff 1999).
Soil depth classes are very shallow (depth <25 cm, except where noted as
<18 cm), shallow (25–50 cm), moderately deep (50–100 cm), deep (100–150
cm), and very deep (>150 cm).
Peridotite is easy to identify where rock surfaces have weathered to
reddish brown and have a few millimeters of knobby relief with pyroxene
highs and olivine lows (Figs. 1–2 in Alexander et al. 2007). Serpentinite
is easy to identify where it has been tectonically sheared to reveal smooth
greenish mottled surfaces, or where rocks have weathered to smooth gray
surfaces (Alexander 2004). Where the ultramafic rocks are massive and lack
distinctive weathering surfaces, partially serpentinized peridotite can be
recognized by the cleavage faces of pyroxenite in freshly broken rocks. All
of the ultramafic rocks in the RCT are at least partially serpentinized (except
pyroxenite, which is not extensive)—the presence or absence of pyroxene
cleavage faces seemed to be a good criterion for distinguishing between
peridotite that has been only partially serpentinized and serpentinite lacking
pyroxene (Alexander 2003).
Surface boulder (nominal diameter >60 cm), “stone” (25–60 cm), and
cobble (7.5–25 cm) cover were estimated by 100 step-point counts at each
soil-description site. Soils were given color designations from a Munsell chart
(Munsell 1988). These color designations were converted to redness ratings
(Rr) by subtracting the prefix to YR from 15 (or 15 minus 12.5 for 2.5Y hues),
multiplying by the chroma, and dividing by the value (Alexander 2004). The
redness ratings were assigned to classes, allowing a comparison of differences
between soils on peridotite and serpentinite by chi-square (χ2) statistics.
Plant species cover (percentage) was estimated visually at each of the
208 soil-description sites. Because the sites were chosen to represent soiltopography
map units, vegetation bias in choosing the sites was minimal.
The soil site data are suitable only for indicating the distribution of the more
common plant species. Serpentine endemic species (6 species) distributions
in the RCT were investigated by Williams et al. (2009).
Soil horizon samples from two pedons were analyzed in a laboratory.
These pedons represent the most extensive shallow soils on peridotite (Wildmad
series) and serpentinite (Bramlet series). Cations were extracted with
0.5 M KCl, and Ca and Mg were measured by EDTA titration (Heald 1965).
Acidity was extracted with KCl-nitrophenol buffer, pH 7.0, and with BaCl2-
TEA buffer, pH 8.2, and the buffer solutions were titrated to a bromocresol
green endpoint with standard hydrochloric acid, following procedure modifications from Schofield (1933) and Peech (1965). Soil pH was ascertained
with a glass electrode after 30 minutes in 1:1 water to soil suspensions. Iron
and Mn were reduced and extracted with Na-dithionite in 0.3 M Na-citrate
(Holmgren 1967) and analyzed by atomic absorption spectrometry. Soil
organic matter (SOM) is approximately equal to the loss on ignition (LOI)
182 Northeastern Naturalist Vol. 16, Special Issue 5
at 360 °C. It was estimated from the equation SOM = 0.88 LOI - 0.14 Fed,
where Fed is the citrate-dithionite extractable Fe. This equation is based on
data from Alexander et al. (1989) for LOI and for SOM by weighing CO2
produced by dry combustion. Soil organic matter was assumed to be twice
the weight of organic carbon.
Mean differences for tree, shrub, and grass cover on soils in two parent
material classes and four soil habitat classes were compared by two-way
analysis of variance (ANOVA). Because the number of samples in each
soil parent-material class and in each soil habitat class were different, comparisons
among individual classes were not appropriate (Havicek and Crain
1988, Kachigan 1986).
Results
Topography and soils
The frequencies of very steep slopes (gradient >60%) on soils mapped
in peridotite landscapes are thought to be much greater than those in serpentinite
landscapes (Figs. 2 and 3). Soil and rock detritus that has accumulated
downslope in landslides is more common in serpentinite landscapes than in
peridotite landscapes. Peridotite colluvium that has accumulated on steep or
very steep slopes, or near the base of those slopes, is generally expected to
be coarser than serpentinite colluvium. Although some of the soil description
data support this conjecture, too few sites were described in these colluvial
positions to test this idea objectively. Obvious extremes are blocky
talus of dunite lacking particles <7.5 cm in High Camp basin at the head of
the Trinity River and fine serpentinite slopes of the Lassics area, about 18
km southwest of the RCT, lacking particles >7.5 cm. In the RCT, the mean
stone cover was 1% boulders, 4% “stones,” and 13% cobbles at 73 peridotite
sites, and much less than 1% boulders, 1% “stones,” and 5% cobbles at 108
serpentinite sites. The ground cover at one peridotite colluvium site with a
well-vegetated Palexeralf was about 10% “stones” and 75% cobbles. Peridotite
sites with greater stone cover were observed, but not sampled, because
they generally lack fine earth (particles <2 mm) and vegetation.
A typical horizon sequence in both peridotite and serpentinite soils of the
RCT is Oi-A-Bt-C-R, with relatively few soils having Bw rather than Bt horizons.
The most obvious difference between the peridotite and serpentinite
soils is that the peridotite soils are redder. Table 1 contains a summary of soil
redness for all shallow and moderately deep to deep serpentine Argixerolls
and Haploxeralfs sampled in the RCT. Very deep soils and soils lacking
argillic horizons were not included in this summary. The χ2 statistic for a
comparison of redness class differences for peridotite and serpentinite soils
is 70.6 with 3 degrees of freedom, which is highly significant (α < 0.01).
Table 2 contains data from representative shallow soils with mesic soil
temperature regimes on peridotite (Wildmad series) and serpentinite (Bramlet
series). There are data from too few pedons to make many comparisons
of chemical differences. It is obvious from the data (Table 2), however,
2009 E.B. Alexander 183
that dark colors (low values and chroma) are not entirely related to soil organic
matter content. Greater Fe oxide concentrations in soils on peridotite
increases chroma and tends to diminish the effects of organic matter on soil
colors. Free Fe and Mn were extracted from three soil samples: Wildmad A
Figure 2. Typical serpentine soils and vegetation on a steep east-facing slope in the
southern exposure of RCT. Although logs were taken from some of the sites many
years ago, the forests on serpentinite were never dense. On the left is a shallow
Bramlet soil with a Jeffrey Pine–Incense Cedar/Buckbrush plant community, and
on the right is a moderately deep Hyampom soil with a Jeffrey Pine–Incense Cedar/
fescue plant community.
Table 1. Soil redness based on Munsell colors (moist) of subsoils in shallow (18–50 cm) and
moderately deep to deep (50–150 cm) serpentine soils with argillic horizons. The expected
value is the product of the number of samples in a row and the number of samples in the column
divided by the total number of samples (126). The χ2 value is 70.6, with 3 degrees of freedom
(α < 0.01).
Number of samples (pedons)
Peridotite Serpentinite
Redness class Observed Expected Observed Expected
Low, Rr <5 2 18.2 44 27.7
Moderate, Rr 5.1–10 11 15.1 27 22.9
Mod. High, Rr 10.1–15 20 9.5 4 14.5
High, Rr >15 17 7.1 1 10.9
Total (126 pedons) 50 50.0 76 76.0
184 Northeastern Naturalist Vol. 16, Special Issue 5
(4.0% Fe, 0.13% Mn) and Bt (4.5% Fe, 0.12% Mn) horizons and Bramlet
Bt (1.3% Fe, 0.05% Mn) horizon. X-ray diffractograms of clay from Wildmad
(National Soil Survey Laboratory, NSSL pedon 04N0625) and Bramlet
(NSSL pedon 03N0075) soils indicate that the main clay mineral is serpentine,
apparently with a bit of chlorite/vermiculite mineral as found by Lee
et al. (2003) elsewhere in the Klamath Mountains and in the Bramlet pedon
minor talc.
Table 2. A comparison of shallow peridotite and serpentinite soils with mesic soil temperature
regimes in the Rattlesnake Creek terrane.
Exchangeable cations
Soil horizon (mmol+/kg)
Depth Color Field Soil OMB Bases Acidity Ca:Mg
Sym. (cm) moist gradeA (g/kg) Ca Mg pH 7 pH8 (mol/mol) pH
Wildmad series, a Lithic Haploxeralf, pedon TS42
Oi 3–0 Slightly matted pine needles.
A 0–5 7.5YR 2/2 GrSL 95 61 166 44 105 0.37 6.3
AB 5–12 7.5YR 3/3 GrSL 42 35 175 18 77 0.20 6.4
Bt 12–33 5YR 3/4 vGrL 29 22 161 15 66 0.14 6.6
R 33+ Moderately fractured partially serpentinized peridotite
Bramlet series, a Lithic Ultic Argixeroll, pedon TS26
Oi 3–0 Slightly matted pine needles.
A1 0–2 10YR 2/1 vGrSL 32 16 83 8 38 0.19 6.2
A2 2–12 10YR 2/1 vGrSL 23 11 82 2 29 0.13 6.4
Bt 12–26 10YR 2/2 vGrSL 18 11 96 3 29 0.11 6.5
R 26+ Highly fractured serpentinite
AField grade symbols: GrSL, gravelly sandy loam; vGL, very gravelly loam; vGrSL, very
gravelly sandy loam.
BOrganic matter estimated from loss-on-ignition at 360 °C, with an adjustment for citratedithionite
extractable iron.
Figure 3. Slope
d i s t r i b u t i o n s
of serpentine
soils as mapped
in the southern
exposure of the
R a t t l e s n a k e
Creek terrane.
The slope classes
are landslide,
m o d e r a t e l y
steep (15–30%),
steep (30–60%),
and very steep
(>60%).
2009 E.B. Alexander 185
Conceptual transects from south to north across a very steep peridotite
mountain (1334 m asl) and nearby steep peridotite and serpentinite mountains
indicate the soils encountered (Fig. 4). On very steep slopes (gradient
>60%), which are common only on peridotite, rock outcrops and very shallow
Entisols (Lithic Xerorthents) are characteristic of upper slopes. Further
down very steep slopes, there are some very deep north-facing Inceptisols
(Haploxerepts) and very deep south-facing Alfisols (Haplic Palexeralfs).
Soils on serpentinite can be readily compared to those on peridotite on steep
slopes (30–60% gradient), because steep slopes are common on both kinds of
rocks. Alfisols predominate on peridotite: mostly Lithic Haploxeralfs on
south-facing slopes and moderately deep to deep Mollic Haploxeralfs on
north-facing slopes. On serpentinite, moderately deep to deep Alfisols (Mollic
Haploxeralfs) predominate on north-facing slopes, and there are some
shallow Mollisols (Argixerolls). Shallow Mollisols (Argixerolls)
predominate on south-facing serpentinite slopes, with some moderately deep
Mollisols (Ultic Argixerolls) and Alfisols (Mollic Haploxeralfs). Moderately
deep soils with mesic soil temperature regimes are predominantly in clayeyskeletal
families on peridotite and in loamy-skeletal families on serpentinite.
Otherwise, the soils with mesic soil temperature regimes are mostly in
Figure 4. Profile
sketches of very
steep and steep
slopes on peridotite
(A) and steep slopes
on serpentinite (B)
in the Rattlesnake
Creek terrain.
186 Northeastern Naturalist Vol. 16, Special Issue 5
loamy-skeletal families, and those with thermic soil temperature regimes are
mostly in clayey-skeletal families.
Soils grouped by four habitat classes that were defined to show vegetation
differences related to soil depth and slope aspect are displayed in
Table 3. The very shallow soils are mostly Entisols (Lithic Xerorthents) on
peridotite and Mollisols (Lithic Haploxerolls) on serpentinite.
Vegetation
Differences related to longitude and elevation in the RCT are much greater
for vegetation than for soils. These vegetation differences were minimized
by restricting the comparison of vegetation to mesic soil temperature regimes
in the southeastern half of the terrane where the vegetation was described
at 84 sites on moderately steep to steep slopes: 44 sites on peridotite and 40
on serpentinite. Two-way ANOVA for tree, shrub, and grass cover (Table 4)
indicates a significant difference (α < 0.05) for tree cover among the soil
habitat classes, with very low tree cover on very shallow soils. Although
there are large differences in grass cover on peridotite compared to serpentinite
soils and in tree cover (Pinus jeffreyi (Grev. & Balf.) [Jeffrey Pine],
Calocedrus decurrens (Torrey) Florin [Incense Cedar], and Pseudotsuga
menziesii (Mirabel) Franco [Douglas Fir]) on very shallow soils, because of
large variance these differences are not statistically significant.
Figure 5 shows some large differences in species cover between peridotite
and serpentinite soils. Conifer trees (Jeffrey Pine > Incense Cedar > Douglas
Fir) are the dominant cover on north-facing serpentinite slopes and all peridotite
soils, except very shallow ones. Quercus durata Jepson (Leather Oak)
is the predominant shrub on very shallow peridotite soils and moderately
deep to deep serpentinite soils that are not on north-facing slopes, but it is absent
from very shallow serpentinite soils. Ceanothus cuneatus (Hook.) Nutt.
(Buckbrush) is the predominant shrub cover on shallow serpentinite soils.
Other than Buckbrush, Leather Oak, and Arctostaphylos viscida C. Parry
(Whiteleaf Manzanita), other shrub species of Arctostaphylos spp. (manzanita),
Garrya spp. (Silktassel), and Rhamnus spp. (Coffeeberry) are common
in small amounts in the mesic soil habitats. Grasses, mainly perennial fescues
(much Festuca idahoensis Elmer [Idaho Fescue], and less F. californica
Vasey [California Fescue]), are more abundant on serpentinite than on
Table 3. Dominant kinds of soils in four different soil habitat classes, based on 159 pedon descriptions
in upland soils (66 on peridotite and 93 on serpentinite). Habitat class definitions:
very shallow soils = depth <18 cm for soils with argillic horizons, or depth <25 cm for other
soils; shallow soils = those not very shallow and with depth <50 cm on S-facing slopes or
depth <30 cm on N-facing slopes; deep soils = depth 50–150 cm on S-facing slopes, and depth
30 to 150 cm on N-facing–slopes with aspect 300o to 120o azimuth.
Habitat class Peridotite Serpentinite
Very shallow soils Entisols Haploxerolls
Shallow soils Alfisols Argixerolls
Deep soils Alfisols Argixerolls and Alfisols
North-facing slopes Alfisols Alfisols and Argixerolls
2009 E.B. Alexander 187
Table 4. Tree, shrub, and grass cover differences between peridotite and serpentinite and among soil habitat classes.
A. Means and standard deviation by soil parent material and soil habitat class (mean ± standard deviation)
Number of samples Tree cover Shrub cover Grass cover
Soil habitat class Peridotite Serpentinite Peridotite Serpentinite Peridotite Serpentinite Peridotite Serpentinite
Very shallow 5 5 14.4 ± 10.7 2.0 ± 1.9 14.2 ± 14.6 22.8 ± 28.2 2.0 ± 4.5 8.2 ± 8.9
Shallow 12 17 29.5 ± 12.9 18.3 ± 16.9 14.8 ± 15.9 18.2 ± 19.1 5.3 ± 9.7 5.7 ± 8.1
Deep, south 11 6 30.6 ± 18.2 22.5 ± 13.9 25.0 ± 11.6 39.2 ± 22.4 1.3 ± 1.9 10.2 ± 10.5
North-facing 16 12 35.9 ± 12.2 39.2 ± 14.1 11.2 ± 10.6 8.8 ± 10.8 2.4 ± 5.1 7.6 ± 8.3
B. Significance of differences rated by two-way analysis of variance (ANOVA)
Degrees Trees Shrubs Grass
Source of difference of freedom SS MS F SS MS F SS MS F
Parent material 1 1104.1 1104.1 5.39 201.4 201.4 0.30 403.1 403.1 7.15
Soil habitat 3 7001.1 2333.7 11.38* 4167.0 1389.0 2.05 18.9 6.3 0.11
Interaction 3 492.3 164.1 0.80 3221.6 1073.9 1.28 187.1 62.7 1.11
Within subclasses 76 15,580.3 205.0 51,580.3 678.7 4284.7 56.4
*Significant (α < 0.05).
188 Northeastern Naturalist Vol. 16, Special Issue 5
peridotite soils. Vulpia microstachys Nutt. (Annual Fescue) is more abundant
than perennial fescues on very shallow serpentinite soils and is common
on shallow serpentinite soils, but it is practically absent from all other
Figure 5. Major plant species distributions in soil habitat classes with mesic soil
temperature regimes. A. Peridotite sites, n = 45. B. Serpentinite sites, n = 40. Plant
species symbols for trees: DF = Douglas Fir (Pseudotsuga menziesii), IC = Incense
Cedar (Calocedrus decurrens), JP = Jeffrey Pine (Pinus jeffreyi); for shrubs: Avi =
Whiteleaf Manzanita (Arctostaphylos viscida), Ccu = Buckbrush (Ceanothus cuneatus),
Qdu = Leather Oak (Quercus durata); and grass: Fescue (Festuca idahoensis
and F. californica).
2009 E.B. Alexander 189
serpentinite and all peridotite soils. Two of the more ubiquitous but sparse
forbs are Phacelia corymbosa Jepson (Serpentine Phacelia) and Streptanthus
spp. (jewelflower). The Phacelia shows no habitat preference. Jewelflower is
present on only 9% of the peridotite sites, but occurs on 36% of the serpentinite
sites. These species of jewelflower are not Ni-hyperaccumulators.
Angiosperm trees, with the rare exception of a Quercus chrysolepis
Liebm (Live Oak) or an Arbutus menziesii Pursh (Madrone),
both evergreen species, are absent from peridotite and serpentinite in
the southeastern part of the RCT. Deciduous oak trees are absent from the
peridotite and serpentinite, but a shrubby variety of Quercus var. garryana
breweri (Engelm.) Jepson (White Oak) is common on pyroxenite soils.
All of the more common shrub species on serpentinite and peridotite soils
are evergreen. There are only a few hectares of pyroxenite soils in the
southern exposure of the RCT.
Discussion
The greater frequencies of very steep slopes on peridotite and of landslides
in serpentinite terrain reflect the greater rock strength of peridotite and
the more extensive fracturing in serpentinite, respectively. Also, the lesser
frequencies of large stones on serpentinite soils has been attributed to the
more extensive fracturing in serpentinite than in peridotite.
The main serpentine soil-forming processes are chemical weathering,
oxidation of Fe, accumulation and migration of clay, and accumulation of
organic matter and its incorporation into soils (Alexander et al. 2007). A
typical horizon sequence is Oi-A-Bt-C-R. Most of the organic matter is in
the soils rather than in the Oi horizons of plant detritus. Peridotite soils are
generally redder than serpentinite soils because peridotite has more Fe in
readily weathered minerals and less in resistant spinel group minerals such
as chromite and magnetite (Alexander 2004). Intense reddish colors, or high
chroma, resulting from relatively high Fe-oxide contents may be the reason
that more peridotite soils are Alfisols and more serpentinite soils are Mollisols,
rather than because of differences in organic matter content. Munsell
(1988) soil colors of high chroma (chroma >3 moist) are not mollic epipedon
colors, even with dark values of 3 (Soil Survey Staff 1999), preventing many
dark-colored peridotite soils from being Mollisols.
The presence of clayey, moderately deep peridotite soils with mesic soil
temperature regimes, where the majority of serpentinite soils are loamy, is
not readily explicable. Perhaps the more weatherable silicate minerals in
peridotite keep the free silicon concentrations higher in peridotite soil and
promote the formation of silicate clay minerals. In wetter climates, much
excess silicon is leached away as H4SiO4, leaving peridotite soils with very
high concentrations of Fe oxides; for example, an Ultisol of the Littlered
series in the California Coast Ranges, adjacent to the Klamath Mountains,
has 33.2% citrate-dithionite extractable Fe (pedon S80CA-045-002, 25–66
cm depth), which would be 53% goethite (FeOOH).
190 Northeastern Naturalist Vol. 16, Special Issue 5
Because Ca is generally lost in the serpentinization process, serpentinite
parent materials have less calcium than peridotite parent materials. The data
in Table 2 indicate that the soil on serpentinite (Bramlet series) has lower
Ca/Mg ratios than the soil on peridotite (Wildmad series), but there are data
from too few pedons to assume that this is a general rule.
It is not obvious why conifer tree cover might be greater on shallow peridotite
soils than on shallow serpentinite soils (Fig. 5). Perhaps more water is
lost by overland flow from serpentinite, rather than infiltrating into the soils.
Peridotite soil depths appear to be less uniform than serpentinite soil depths;
consequently, conifer trees and Leather Oak on very shallow peridotite soils
may be exploiting inclusions of deeper pockets of soil.
Other than rock outcrop and blocky talus in very steep peridotite terrain,
most of the barrens with sparse vegetative cover are on very shallow serpentinite
soils. Limited soil-water supplies, lack of shade, and high albedo
of serpentinite, makes these soils poor environments for plants, especially if
overland flow of water carries any of the scanty plant detritus away before it
can be incorporated into the soils.
Obviously, significant differences in tree cover related to soil habitat
(Table 4) are mainly the result of less cover on very shallow soils, although
a statistical comparison among soil habitat classes was not possible. Apparent
greater tree cover on very shallow peridotite than on very shallow
serpentinite soils and greater grass cover on serpentinite soils than on
peridotite soils were not verified by statistical analyses, but some species
differences are so definite that statistical analysis is not necessary to verify
their significance. This clear significance is true for the dominance among
shrubs of Leather Oak on peridotite and Buckbrush on serpentinite soils. It
is also true for the occurrence of Annual Fescue almost exclusively on very
shallow and shallow serpentinite soils; it is more abundant than perennial
fescues on very shallow serpentinite soils.
Summary
Differences in soils from peridotite to serpentinite are more obvious than
differences in vegetation, except for vegetation on very shallow soils. A
large set of data from the RCT indicates that the slopes are generally steeper
on peridotite and the soils are redder than on serpentinite. Although there are
many other differences between soils on peridotite and serpentinite, the data
for them are less definitive. Alfisols are the predominant peridotite soils, and
both shallow Mollisols and moderately deep Alfisols are the predominant
serpentinite soils with mesic soil temperature regimes.
Apparent physiognomic differences of greater tree cover on very shallow
peridotite than on very shallow serpentinite soils and greater grass cover
on serpentinite soils than on peridotite soils were not verified by statistical
analyses. The occurrence of Annual Fescue only on very shallow and shallow
serpentinite soils, however, is an obvious distinction from peridotite
soils. Also, on very shallow soils, the complete dominance of Leather Oak
among shrubs on peridotite and Buckbrush on serpentinite is unequivocal.
2009 E.B. Alexander 191
Acknowledgments
A detailed soil survey of the RCT was possible only because Julie Nelson and
Scott Miles of the Shasta-Trinity National Forest recognized the importance of soils
information for managing the area for the endangered and sensitive serpentine plants
and were able to obtain funds to support the soil survey. Susan Erwin, Trinity National
Forest botanist, was very helpful in facilitating the soil survey.
Literature Cited
Alexander, E.B. 2003. Trinity Serpentine Soil Survey. Available online at www.
fs.fed.us/r5/shastatrinity/. Shasta-Trinity National Forest, Redding CA, USA.
Accessed 2003.
Alexander, E.B. 2004. Serpentine soil redness: Differences among peridotite and
serpentinite materials, Klamath Mountains, California. International Geology
Review 46:754–764.
Alexander, E.B., C. Adamson, P.J. Zinke, and R.C. Graham. 1989. Soils and conifer
productivity on serpentinized peridotite of the Trinity ophiolite, California. Soil
Science 148:412–423.
Alexander, E.B., R.G. Coleman, T. Keeler-Wolf, and S.P. Harrison. 2007. Serpentine
Geoecology of Western North America. Oxford University Press, New
York, NY, USA.
Brooks, R.R. 1987. Serpentine and Its Vegetation. Dioscorides Press, Portland, OR,
USA. 454 pp.
Coleman, R.G. 1971. Petrologic and geophysical nature of serpentinites. Geological
Society America, Bulletin 82:897–918.
Diller, J.S. 1902. Topographic development of the Klamath Mountains. US Geological
Survey, Washington, DC. Bulletin 196. 69 pp.
Havlicek, L.L., and R D Crain. 1988. Practical Statistics for the Physical Sciences.
American Chemical Society, Washington, DC, USA. 489 pp.
Heald, W.R. 1965. Calcium and magnesium. Pp. 999–1010, In C.A. Black (Ed.).
Methods of Soil Analysis, Part 2, Chemical and Microbiological Properties.
American Society of Agronomy, Madison, WI, USA. 1572 pp.
Holmgren, G.G.S. 1967. A rapid citrate-dithionite extractable-iron procedure. Soil
Science Society of America Proceedings 31:210–211.
Kachigan, S.K. 1986. Statistical Analysis. Radius Press, New York, NY, USA. 589 pp.
Kruckeberg, A.R. 1984. California Serpentines: Flora, Vegetation, Soils, and Management
Problems. University of California Press, Berkeley, CA, USA. 180 pp.
Lanspa, K.E. 1993. Soil Survey of Shasta-Trinity Forest Area, California. USDA,
Forest Service, Shasta-Trinity National Forest, Redding, CA, USA. 521 pp.
Lee, B.D., S.K. Sears, R.C. Graham, C. Amrhein, and H. Vali. 2003. Secondary mineral
genesis from chlorite and serpentine in an ultramafic soil toposequence. Soil
Science Society of America Journal 67:1309–1317.
Munsell, A.H. 1988. Munsell Soil Color Chart. Kollmorgan Instruments, Baltimore,
MD, USA.
Peech, M. 1965. Exchange acidity. Pp. 905–913, In C.A. Black (Ed.). Methods of
Soil Analysis, Part 2, Chemical and Microbiological Properties. American Society
of Agronomy, Madison, WI, USA. 1572 pp.
Schofield, R.K. 1933. The use of p-nitrophenol for assessing lime status. Journal of
Agricultural Science 23:252–254.
192 Northeastern Naturalist Vol. 16, Special Issue 5
Soil Survey Staff. 1999. Soil Taxonomy: A Basic System for Making and Interpreting
Soil Surveys. Agriculture Handbook No. 436. US Government Printing Office,
Washington, DC, USA. 869 pp.
Williams, J.N., C. Seo, J. Thorne, J.K. Nelson, S.Erwin, J.M. O’Brien, and M.W.
Schwartz. 2009. Using species distribution models to predict new occurrences
for rare plants. Diversity and Distributions 15:565–576.
Wright, J.E., and S.J. Wyld. 1994. The Rattlesnake Creek terrane, Klamath
Mountains,California: An early Mesozoic volcanic arc and its basement of
tectonically disrupted ocean crust. Geological Society of America Bulletin
106:1033–1056.
