Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
136
Canaan Valley & Environs
2015 Southeastern Naturalist 14(Special Issue 7):136–157
Plant Communities of Abes Run Wetland, Canaan Valley
State Park, West Virginia
James S. Rentch1,*, Ronald H. Fortney2, 3, James T. Anderson1, and
William N. Grafton1,3
Abstract - Abes Run wetland is a biologically diverse, 82-ac (33-ha) complex of wet
meadow, marsh, scrub-shrub, and forested-swamp communities in Canaan Valley, WV. In
2002, we sampled the vegetation in six 65-ft (20-m)-wide transects and identified a total
of 179 vascular plant species. We classified 23 species as introduced; 38 occurred at or
near the southernmost known limit of their range. Two graminoid-dominated (e.g., Carex
spp. [sedges], Leersia spp. [cutgrass], and Scirpus spp. [bulrush]) and forb-dominated
(Euthamia spp. [goldenrods]) transects occurred in an area that had been forested and later
inundated by Castor canadensis (North American Beaver) in the 1970s. Four transects
were mixed-deciduous and coniferous forested-swamp communities. With the exception
of transect 5, these sites had an organic horizon that was 32–40-in (80–100-cm) deep in
the center, and the water table tended to persist at the wetland surface through the first
half of the growing season. The tree stratum was well-developed, although discontinuous,
and was dominated by mixtures of Fraxinus nigra (Black Ash), Abies balsamea
(Balsam Fir), Picea rubens (Red Spruce), and Betula alleghaniensis (Yellow Birch). A
rich shrub layer of Rhamnus alnifolia (Alder-leaved Buckthorn), Ilex verticillata (Winterberry),
and Alnus incana ssp. rugosa (Speckled Alder) was also present. The broken
overstory created a variable light regime on the wetland floor and as a consequence, there
was high diversity of herbaceous plants. Although a rank comparison of 1945 vs. 1997
vegetative-cover classes did not yield any significant differences, we noted 3 trends:
1) North American Beaver activities reduced the area of coniferous swamp forests,
2) wet-graminoid areas increased as beaver dams were abandoned and their impoundments
dried, and 3) the extent of scrub-shrub communities increased, particularly in the
upper portions of the wetland’s drainage.
Introduction
Canaan Valley (hereafter, the Valley), in northeastern West Virginia, contains
one of the largest inland freshwater wetland complexes in the eastern US.
Because of a unique combination of human and natural disturbances, surficial
geomorphology, cool climate, frost-pocket effect, and the juxtaposition of upland
and wetland habitats, the Valley’s diverse wetlands provide habitats for a large
number of rare plant species and rare plant communities (Allard and Leonard
1952, Fortney 1993, Fortney and Rentch 2003, Fortney et al. 2015 [this issue]).
Notable among them is the wetland associated with Abes Run in Canaan Valley
State Park. This is an 82-ac (33-ha) complex that includes marsh, wet meadow,
1Division of Forestry and Natural Resources, West Virginia University, PO Box 6125
Morgantown, WV 26506-6125. 2Department of Civil and Environmental Engineering,
West Virginia University, PO Box 6103, Morgantown, WV 26506-6103. 3Deceased. *Corresponding
author - jrentch2@wvu.edu.
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
137
scrub-shrub, and forested-swamp communities. Among the rare plants that have
been previously found there are Euphorbia purpurea (Glade Spurge), Polemonium
van-bruntiae (Jacob’s Ladder), Cypredium reginae (Showy Lady’s Slipper),
Rhamnus alnifolia (Alder-leaved Buckthorn), Viburnum opulus var. americanum
(Highbush Cranberry), and Abies balsamea (Balsam Fir) (Harmon et al. 2006).
In December 2001, we initiated a comprehensive study of the soils, hydrology,
and vegetation of Abes Run wetland. This site offered advantages for our study.
The wetland and its surrounding watershed are relatively small and well-defined,
and comprehensive sampling and monitoring activities were feasible and not
hampered by problems of scale. In addition, the wetland lies in a state park, so
the site is protected and relatively accessible. The objectives of this paper were
to (1) report on the results of hydrology, soils, and vegetation sampling in Abes
Run, and (2) identify trends in the development of vegetation in the post-loggingera
in the watershed.
Study Area
Abes Run wetland is part of a small, 370-ac (150-ha) watershed in the southern
end of Canaan Valley State Park (Fig. 1). In 1997, the total wetland area,
defined by aerial imagery of vegetation (Fortney and Rentch 2003), was ~82 ac
(33 ha). The general aspect of the watershed is north-facing, and its total relief is
approximately 1228 ft (374 m) from the crest of Cabin Mountain (4528 ft [1372
m]) on the south, to the confluence of Abes Run and Mill Run (3300 ft [1006 m]).
Relief of the wetland portion of the watershed is ~16 ft (5 m) over 2625 ft (800 m)
of distance. Abes Run is bordered primarily by open fields, mowed meadows, and
upland mixed-deciduous–conifer forests. An access road to the state park forms
the downstream (northern) boundary of the study area.
The Valley’s climate is moderate to extreme, with long, cold, snowy winters,
cool to moderate summers, and a short growing season. The average freeze-free
period is 90 days (Loche and Beverage 1967), and frost may occur during any
month of the year. Mean January and July temperatures are 25.7 ºF (–3.5 ºC)
and 65.6 ºF (18.7 ºC), respectively. Annual precipitation averages 55 in (127.2
cm), with much of this falling as snow (123 in [312 cm]) (NCDC 2003). A distinguishing
climatic feature is the frost-pocket effect, which depresses nighttime
temperatures on the Valley’s floor.
Methods
Groundwater sampling
During the winter of 2001, we installed twenty-one 2-in (5-cm) PVC
groundwater-monitoring wells along 6 transects in Abes Run. Transects extended
perpendicular to the direction of stream flow from the edge of the upland
forested community across the wetland to the upland forest edge. The number
of wells installed in each transect varied with transect length, ranging from 2 to
5, in transects 5 and 4, respectively. We placed the bases of the wells at the top
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
138
of the low-conductivity clay layer that lay beneath the wetland; average well
depth was 34 in (86 cm), and the average screen interval was 22 in (55 cm). Between
21 December 2001 and 12 August 2002, we measured depth to the water
table twice monthly using a Solinst Mini 101® (Solinst Canada Ltd., Georgetown,
ON, Canada) water-level meter. In this paper, we present the results from
the center well of each transect for only one growing season (1 May–September).
We also report percent days of continuous standing water and saturation
within 12 in (30 cm) of the surface.
Soil sampling
J. Gorman of the Department of Plant and Soil Sciences at West Virginia
University, Morgantown, WV, sampled soils during July 2002. He extracted
samples with a Dutch auger to a depth of 39 in (100 cm) at the center of each
transect and at the two forest–wetland boundaries. Using his samples, we described
soil horizons by texture, depth, matrix color, and redox concentrations.
We determined texture by the feel method and color by Munsell soil color
charts. For the transect-center sampling points, we report only depth of organic
and mineral horizons.
Vegetation sampling
In July 2002, we conducted vegetation sampling along 6 belt transects
(Fig. 1). Transects were 66 ft (20 m) wide and ranged from 213 to 427 ft (65
to 130 m) long. We permanently marked all transect centers with a steel pin.
Within each transect, we determined composition and structure of the vegetation
using the following methods. For trees (diameter breast height [dbh] > 3.9
in [10 cm]), small trees (1 in [2.5 cm] < dbh < 3.9 in [10 cm]), and saplings (dbh
< 1 in, [2.5 cm], height > 3.3 ft (1 m]), we conducted a 100% tally by species
and size class. For shrubs and tall tree seedlings (height > 3.3 ft [1 m]), we tallied
stems by species every 33 ft (10 m) along the centerline in 16.4 ft x 16.4 ft
(5 m x 5 m) subplots. For herbaceous plant species, we estimated percent cover
in 3.3 ft. x 3.3 ft (1 m x 1 m) subplots sited at 16.4-ft (5-m) intervals along the
centerline. We estimated cover value using a cover-class rating scale (Daubenmire
1968). We also compiled a list of additional species observed during a
walk-around within the belt transect but outside the sample subplots. We conducted
an additional walk-through on 30 August 2002 to identify plants that we
had not tallied during the July sampling.
We used field data to calculate basal area and density values separately for
the tree and small tree categories. We calculated only density values for saplings,
seedlings, and shrubs and determined average cover and frequency for herbaceous
plants. We calculated species importance-value (IV) indices for trees and
small trees as one-half the sum of relative basal area and relative density, and for
herbaceous plants as one-half the sum of relative cover and relative frequency.
Species diversity (H') and evenness (E) indices were computed using PC-ORD
software (Ver. 4.0, McCune and Mefford 1999).
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
139
We classified all species of vascular plants as either native or introduced, using
a checklist by Harmon et al. (2006). From all plants identified and collected, we determined
those at the northern or southern extent of their ranges using Core (1966),
Fortney (1975), Strausbaugh and Core (1977), Gleason and Cronquist (1991),
and Pitillo (1994). Nomenclature for vascular plant species followed Harmon et
al. (2006). We collected bryophyte specimens during a walkthrough of each belt
transect in the winter of 2001, and S.M. Studlar of the Department of Biology, West
Virginia University, Morgantown, WV, identified them. Nomenclature of bryophytes
followed Studlar et al. (2002). Species scientific names and authorities, as
well as common names, are provided in Tables 1–5.
We assessed the conservation value of each transect using a floristic qualityindex
(FQI) technique adapted for West Virginia’s wetlands (Rentch and Anderson
2006). This method assigns each species a coefficient of conservatism value (C)
Figure 1. Vegetation-cover classes and approximate locations of 6 belt-transects in Abes
Run wetland, Canaan Valley State Park, WV. Cover classifications follow Cowardin
et al. (1979). PSS1 = palustrine, scrub-shrub, broad-leaf deciduous; PEM = palustrine,
emergent, persistant; and PFO = palustrine, forested.
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
140
ranging from 0 to 10 based on the species’ tolerance to disturbance and habitat degradation,
as well as fidelity to specific habitats. Default values for exotic species
were 0; species with high C values were generally less tolerant of habitat degradation
and found in fewer higher-quality sites. We calculated mean C as:
Mean C = Σ (C1 + C2 + C3 +….. Cn) / N,
where C is the coefficient of conservatism for each native taxon and N is the total
number of native species inventoried. We then calculated FQI as follows:
FQI = Mean C / N0.5.
In this equation, we included all of the species we tallied in the sample plots, but
not species recorded in the walk-arounds.
In order to determine year of establishment, we extracted increment cores from
several dominant or co-dominant trees within each belt transect. Age determinations
of shrubs, such as Alnus incana ssp. rugosa (Speckled Alder), and smaller
saplings, e.g., Picea rubens (Red Spruce), were made using stem cross-sections.
We sampled at least 2 individuals of each co-dominant species, which yielded a total
of 42 sample chronologies. We prepared sample cores and cross-sections using
standard dendrochronological techniques as outlined by Stokes and Smiley (1968)
and cross-dated samples by matching unique patterns of narrow and wide rings. Annual
rings were counted using a Leica (Buffalo Grove, IL) binocular microscope.
Historic vegetation changes
We identified 52-year successional trends by preparing two geographic information
system (GIS) maps showing whole-watershed vegetation cover classes
based on interpretation of 1945 and 1997 aerial photographic coverages. Sources
and specifications for the aerial imagery were: (1) August 1945, US Department
of Agriculture black and white panchromatic prints, scale = 1:20,000; and
(2) November 1997, US Geologic Survey, National Aerial Photography Program
(NAPP), color-infrared, scale = 1:40,000.
We produced raster-image files by digitally scanning the 1945 aerial photographs
and importing the files into ArcView 3.2 for use as tracing layers in
a heads-up digitization. We used digital elevation-quadrangle (DEQQ) files
of Blackwater Falls 7.5-minute quadrangle maps, which covered the Valley, to
register the 1945 photograph and identified common landmarks on 1992 EPA
Environmental Photographic Interpretation Center (EPIC) land-cover, road,
and stream GIS maps (USEPA 1992). The NAPP imagery had already been
registered and ortho-rectified. In general, we used the central portions of the
photographs for mapping. To compensate for photographic distortions, we used
a GIS warping function.
We based our 1997 map on an updated EPIC (USEPA 1992) cover-class map
of the Valley. Using ArcView 3.2, we projected the EPIC cover-class map over
the NAPP images and modified it based on both the vegetation signature of
1997 images and on our ground-truthing. The 1945 map is an original GIS vector
file based on an interpretation of the USDA 1945 photography. Additional
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
141
details about the preparation of GIS maps and analyses of changes in vegetative
cover classes may be found in Fortney and Rentch (2003). We classified
upland vegetation in the watershed using the EPIC classification system (USEPA
1992); wetland vegetation was classified using Cowardin et al. (1979). Cowardin
classifications were used for analyses and discussion. We evaluated changes in
land-cover classification between 1945 and 1997 by comparing cover-type ranks
using the Kruskall-Wallis test (α = 0.05).
Results
We identified a total of 179 vascular plant and 27 bryophyte species along
the 6 belt transects. Of the vascular plant species, 145 were herbaceous, i.e.,
grasses, sedges, forbs, and ferns (Tables 1, 2), and 34 were woody, i.e, trees,
small trees, shrubs, and woody vines (Tables 3, 4). Grasses and sedges comprised
the most abundant group, with 46 species, and Carex was the most
diverse genus with 18 species. In the herbaceous stratum, 5 species occurred
in all six transects: Carex gynandra (Nodding Sedge), Dryopteris intermedia
(Intermediate Fern), Glyceria striata (Fowl Mannagrass), Polygonum sagittatum
(Tearthumb), and Packera aurea (Golden Ragwort). Thirty-five species
occurred in only one transect. We identified 24 moss and 4 liverwort species in
our bryophyte collection (Table 5).
Harmon et al. (2006) classified 21 of the plant species we collected as exotic.
Of the exotics that occurred in sample subplots, most occurred only once; their
average herbaceous cover value was 1.0% and average importance value was 2.1.
Anthoxanthum odoratum (Sweet Vernal Grass) was the most common herbaceous
exotic, occurring in 5 transects with a maximum IV of 6.3. Rosa multiflora (Multiflora
Rose) occurred in 2 transects, and Elaeagnus umbellata (Autumn Olive) was
noted once. Although the potential for replacement of native species by exotics
appeared greater in the shrub stratum, one exception to this trend was a large population
of Iris pseudoacorus (Yellow Iris) in the lower portion of Abes Run slightly
out of the study area and north of the park access road. No introduced species were
noted in the tree, small tree, or sapling strata.
Of the total 179 species recorded, 38 occurred at or near the southernmost
known limit of their natural range. Notable examples were Balsam Fir, Dryopteris
cristata (Crested Shield Fern), Equisetum sylvaticum (Woodland Horsetail),
Eriophorum virginicum (Cotton-grass), Jacob’s Ladder, Saxifraga pensylvanica
(Swamp Saxifrage), and Glyceria canadensis (Rattlesnake Manna Grass). The
study area is also the northernmost known location for Glade Spurge.
Transect 1
The vegetation on transect 1 had a Cowardin classification of palustrine
emergent persistent (PEM1) and was a graminoid-dominated community in
an area that had been an active beaver pond in the 1970s. Soils in the center of
this transect showed no measurable organic horizon (O); depth to the top of a
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
142
Table 1. Importance values (IV, max = 100) for herbaceous species in 6 transects, Abes Run, Canaan Valley State Park, WV, 2002. * = species at or near
the southernmost limit of their range, ** = introduced species.
Species Common name T1 T2 T3 T4 T5 T6
Achillea millifolium L. var. occidentalis DC** Yarrow 0.2
Agrostis gigantea Roth** Redtop 5.2 4.3 0.8 3.4 1.4
Agrostis hyemalis (Walt.) B.S.P. Hairgrass 0.5 0.3
Anthoxanthum odoratum L. ssp. odoratum** Sweet Vernal Grass 5.8 6.3 0.9 0.5 1.6
Arisaema triphyllum (L.) Schott ssp. stewardsonii (Britt.) Huttleston Bog Jack-in-the-Pulpit 2.7 1.6 0.5 0.9
Asclepia incarnata L. ssp. pulchra (Ehrh. Ex Willd.) Woods Swamp Milkweed 0.9
Asclepias syriaca L. Common Milkweed 1.8
Athyrium felix-femina (L.) Mertens var. angustum (Willd.) G. Lawson* Northeastern Lady Fern 0.7
Brachyelytrum erectum (Schreb. ex Spreng.) Beauv. Northern Shorthusk 0.0 0.5 0.7
Bromus kalmii Gray Canada Bromegrass 0.5
Caltha palustris L. var. palustris* Swamp Marigold 10.1 13.2 5.7 7.4
Cardamine diphylla (Michx.) Wood* Two-leaved Toothwort 0.9
Carex atlantica L. Bailey ssp. atlantica Prickly Bog Sedge 16.8 2.3 2.6 5.3 0.6
Carex baileyi Britt* Bailey’s Sedge 0.3 0.5
Carex bromoides Schkuhr ex Willd. ssp. bromoides* Brome-like Sedge 2.3 3.2 6.5 0.3
Carex cristatella Britton Crested Sedge 0.5
Carex debilis Michx. var. debilis White-edge Sedge 0.9
Carex gynandra Schwein. Nodding Sedge 3.2 3.3 0.4 1.9 6.2 3.5
Carex intumescens Rudge Great Bladder Sedge 1.4 0.3
Carex laxiculmis Schwein. var. laxiculmis Spreading Sedge 0.9 0.7
Carex leptalea Wahl. ssp. leptalea* Bristly-stalk Sedge 0.9 1.8 1.3 1.9 1.4
Carex lurida Wahl. Sallow Sedge 1.7 2.9 0.3
Carex prasina Wahl. Drooping Sedge 2.7 1.0 3.9 3.7
Carex scoparia Schkuhr ex Willd. var. scoparia Pointed Broom Sedge 4.1 1.0
Carex stipata Muhl. Ex Willd. var. stipata Stalk-grain Sedge 1.4 0.4 0.5 0.5
Carex trisperma Dewey var. trisperma* Three-seeded Sedge 1.0 0.4
Carex vulpinoidea Michx. Foxtail Sedge 0.6 0.5
Chelone glabra L. Turtlehead 1.3 0.5 1.6
Chrysoplenium americanum Schwein. ex Hook.* Golden Saxifrage 2.2 0.5 1.4
Cirsium muticum Michx.* Swamp Thistle 0.5
Clematis virginiana L. Virgin’s Bower 0.9 0.5 1.9 2.6
Dennstaedtia punctilobula (Michx.) Moore Hay-scented Fern 10.8 0.5
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
143
Table 1, continued.
Species Common name T1 T2 T3 T4 T5 T6
Doellingeria umbellata (P. Mill.) Nees* Flat-top Aster 0.6 0.3 0.5 0.9
Dryopteris carthusiana (Vill.) H.P. Fuchs Log Fern 2.3 0.9 0.4
Dryopteris cristata (L.) Gray* Crested Shield Fern 3.2 0.7
Dryopteris intermedia (Michx. ex Willd.) Gray Intermediate Shield Fern 2.9 2.2 1.4 0.5 0.5 0.5
Equisetum sylvaticum L.* Woodland Horsetail 0.7
Eupatorium fistulosum Barratt Joe-pye Weed 0.3
Euphorbia purpurea (Raf.) Fern. Glade Spurge 0.4 1.6 1.0 1.6
Euthamia graminifolia (L.) Nutt. var. graminiifolia Grass-leaved Goldenrod 1.7 17.4 1.5 1.4
Fragaria virginiana Duchesne ssp. virginiana Virginia Strawberry 0.9 0.2
Galium asprellum Michx. Rough Bedstraw 0.5 1.8 4.0 1.9 4.0
Galium tinctorium (L.) Scop. Clayton’s Bedstraw 2.4 4.8 1.1 1.0
Galium triflorum Michx. Sweet-scented Bedstraw 0.9
Geranium maculatum L. Wild Geranium 0.9
Geum rivale L.* Purple Avens 0.5 1.0 0.2
Glechoma hederacea L.** Ground-ivy 0.4
Glyceria canadensis (Michx.) Trin.* Rattlesnake Mannagrass 0.9 2.7 1.3 3.2
Glyceria melicaria (Michx.) F.T. Hubb. Mannagrass 1.2 3.6 3.5 0.2
Glyceria striata (Lam.) Hitchc. Fowl Mannagrass 2.9 3.0 9.2 8.8 9.5 5.6
Holcus lanatus L.** Velvet Grass 1.0
Hypericum mutilum L. Small-flowered St. Johnswort 0.6
Impatiens capensis Meerb. Jewelweed 6.9 4.8 5.9 5.9 8.7 5.6
Juncus effusus L. Common Rush 1.1 2.9 0.5
Leersia oryzoides (L.) Sweet Rice Cutgrass 11.2 1.4 2.7 4.7 1.4
Listera smallii Weig. Kidney-leaf Twayblade 0.2
Lycopus uniflorus Michx. Northern Bugleweed 1.0 2.2 0.8 0.5 0.9
Lysimachia ciliata L. Fringed Loosestrife 3.2 4.0 4.8 5.5
Maianthimum canadense Desf..* Canada Mayflower 0.4 0.3 0.5 0.5
Mentha spicata L.** Spearmint 3.5 0.5
Mimulus ringens L. Common Monkey-flower 0.5
Onoclea sensibilis L. Sensitive Fern 4.6 2.4 1.0 8.8
Osmunda cinnamomea L. Cinnamon Fern 4.1 3.4 0.9
Osmunda regalis L. var. spectabilis (Willd.) Gray Royal Fern 1.8 0.5
Oxalis montana Raf. White Wood Sorrel 0.6 1.9 1.8 0.5 1.4
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
144
Table 1, continued.
Species Common name T1 T2 T3 T4 T5 T6
Oxalis stricta L. Yellow Wood Sorrel 1.8
Oxypolis rigidior (L.) Coult. & Rose Cowbane 0.2
Packera aurea (L.) A. & D. Love Golden Ragwort 2.3 0.9 9.6 9.1 7.3 7.7
Phalaris arundinacea L. Reed Canary Grass 1.2 0.9 0.8 0.5
Phleum pratense L.** Timothy Grass 3.0
Poa trivialis L.** Rough Bluegrass 0.6 0.5 0.3 0.5
Polemonium van-bruntiae Britt.* Jacob’s Ladder 0.9 4.8 1.0 1.8
Polygonum hydropiperoides Michx. Mild Water-pepper 1.0 0.2
Polygonum sagittatum L. Arrow-leaved Tearthumb 1.8 2.0 1.8 1.3 4.4 0.7
Potentilla simplex Michx. Common Cinquefoil 0.5
Ranunculus acris L. var. acris** Meadow Buttercup 0.5
Ranunculus hispidus Michx. var. hispidus Hispid Buttercup 0.3 0.2
Ranunculus repens L.** Creeping Buttercup 0.9
Rubus hispidus L. Hispid Dewberry 2.2
Rubus pubescens Raf. var. pubescens Dwarf Red Raspberry 1.5
Rumex crispus L.ssp. crispus** Curly Dock 0.5
Schoenoplectus tabernaemontani (K.C. Gmel.) Palla Great Bulrush 9.6 0.5
Scirpus polyphyllus Vahl Bulrush 0.9
Scutellaria lateriflora L. var. lateriflora Mad-dog Skullcap 0.9
Solidago rugosa P. Mill. ssp. rugosa var. rugosa Wrinkle-leaf Goldenrod 0.6 1.9 1.3 1.0 1.6
Sparganium americanaum Nutt. American Bur-reed 0.9
Sphenopholis intermedia (Rydb.) Rydb. Slender Wedgegrass 0.5
Sphenopholis nitida (Biehler) Scribn. Shining Wedgegrass 1.2 0.5
Symphotrichum prenanthoides (Muhl. ex. Willd.) Nesom Crooked-stem Aster 0.3 0.5 0.2
Symphotrichum puniceum (L.) Nesom var. puniceum Purple-stem Aster 0.9 1.1 2.4 0.5
Taraxacum officinale Weber ex Wigger ssp. officinale** Common Dandelion 0.2
Thalictrum pubescens Pursh Tall Meadow-rue 3.1 1.9 0.2
Tiarella cordifolia L.* Foamflower 0.6 1.8 1.0 1.4
Triadenum virginicum (L.) Raf. Marsh St. Johnswort 1.8
Typha latifolia L. Broad-leaved Cattail 0.4 1.6 0.5
Veratrum viride Ait. False Hellebore 2.7 2.4 1.9
Viola cucullata Ait. Marsh Blue Violet 0.6 2.2 3.0 3.9 4.7
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
145
Table 2. List of additional species observed in walk-arounds on belt transects, but not observed in
the subplots for 6 transects in Abes Run wetland, Canaan Valley State Park, WV, 2002. * = species
at or near the southernmost limit of their range, ** = exotic species.
Species Common name
Agrostis perennans (Walt.) Tuckerman Autumn Bent Grass
Aralia nudicaulis L. Wild Sarsaparila
Bidens vulgata Greene Common Beggartick
Carex projecta Mack.* Necklace Sedge
Carex scabrata Schwein. Rough Sedge
Carex tribuloides Wahl. Blunt Broom Sedge
Cerastium fontanum Baumg. ssp. vulgare (Hartman) Greuter Common Mouse-ear
& Burdet Chickweed
Cinna latifolia (Trev.) Griseb. Drooping Wood Reedgrass
Cinna arundinacea L.* Wood Reedgrass
Circaea lutetiana L. spp. canadensis (L.) Aschers. & Magnus Intermediate Enchanter’snightshade
Cirsium pumilum (Nutt.) Spreng. Bull Thistle
Cirsium vulgare (Savi) Ten.** Common Thistle
Cornus amomum Mill. Silky Dogwood
Dactylis glomerata L. ssp. glomerata** Orchard Grass
Dalibardia repens L.* Star-violet
Danthonia compressa Aust. Mountain Oatgrass
Dichanthelium clandestinium (L.) Gould Deer-tongue Grass
Dipsacus fullonum L.** Common Teasel
Eleocharis tenuis (Willd.) J.A. Schultes var. tenuis Kill Cow
Elaeagnus umbellata Thunb. var parviflora (Royale) Schneid.** Autumn-olive
Epilobium coloratum Biehler Purple-leaved Willow-herb
Epilobium ciliatum Raf. ssp. ciliatum American Willow-herb
Epilobium leptophyllum Raf.* Linear-leaved Willow-herb
Eriophorum virginicum L.* Cotton-grass
Gratiola neglecta Torr. Clammy Hedge-hyssop
Hypericum densiflorum Pursh Glade St. Johnswort
Hypericum ellipticum Hook. Elliptic-leaf St. Johnswort
Hypericum punctatum Lam. Dotted St. Johnswort
Lotus corniculatus L.** Birds-foot Trefoil
Ludwigia palustris (L.) Ell. Marsh Purslane
Oenothera perennis L. Sundrops
Phegopteris connectilis (Michx.) Watt Long Beech Fern
Platanthera grandiflora (Bigelow) Lindl. Large Purple Fringed Orchid
Polygonum hydropiper L. Common Smartweed
Polygonum pensylvanicum L. Pennsylvania Smartweed
Polystichum acrostichoides (Michx.) Schott. Christmas Fern
Portulaca oleracea L.** Common Purslane
Potentilla norvegica L. ssp. monspeliensis (L.) Aschers.& Graebn.** Norwegian Cinquefoil
Ribes rotundifolium Michx. Smooth Gooseberry
Rumex obtusifolius L.** Bitter Dock
Saxifraga pensylvanica L.* Swamp Saxifrage
Scirpus atrocinctus Fern.* Woolgrass
Smilax taminoides L. Hispid Greenbrier
Stellaria graminea L. Lesser Stichwort
Thalictrum pubescens Pursh Tall Meadow-rue
Thelypteris noveborancensis (L.) Nieuwl. New York Fern
Thelypteris palustris Schott var. pubescens (Lawson) Fern. Marsh Fern
Tragopogon pratensis L.ssp. pratensis** Yellow Goat’s Beard
Trifolium aureum Pollich** Yellow Hop Clover
Trifolium repens L.** White Clover
Tusalago farfara L.** Coltsfoot
Viburnum nudum L. var. nudum Wild-raisin
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
146
Table 3. Shrub, woody vinees, and tall seedling (10 cm < height < 1 m) density (stems/ha) for 6 transects in Abes Run wetland, Canaan Valley State Park,
WV, 2002. 1 cm = 0.4 in. 1 ha = 2.49 ac.
Species Common name T1 T2 T3 T4 T5 T6
Abies balsamea (L.) P. Mill Balsam Fir 40
Acer rubrum L. Red Maple 67 571 333 840 1480
Alnus incana (L.) Moench ssp. rugosa (Du Roi) Clausen Speckled Alder 57 667 5000 4480 1480
Amelanchier laevis Weigand Smooth Serviceberry 133
Betula alleghaniensis Britt. Yellow Birch 171 200 40 80
Crataegus punctata Jacq. Dotted Hawthorn 40 120
Fraxinus nigra Marsh. Black Ash 40 160
Hamamelis virginiana L. Witch-hazel 160
Ilex verticillata (L.) Gray Winterberry 67 10,333 9760 5120 2440
Picea rubens Sarg. Red Spruce 133 57 160 560
Prunus serotina Ehrh. Black Cherry 57
Quercus rubra L. Northern Red Oak 40
Rhamnus alnifolia L’Hér. Alder-leaved Buckthorn 28,733 39,920 960 21,960
Rhododendron maximum L. Great Laurel 133 67 200 520
Rosa multiflora Thunb. ex Murr. Multiflora Rose 560 80
Rosa palustris Marsh. Swamp Rose 133 280 320
Rubus allegheniensis Porter var. allegheniensis Allegheny Blackberry 457
Salix discolor Muhl. Pussy Willow 960
Sambucus nigra L. ssp. canadensis (L.) Bolli Black Elderberry 280
Smilax rotundifolia L. Common Greenbrier 67
Spiraea alba Du Roi Meadowsweet 520
Tsuga canadensis (L.) Carr. Eastern Hemlock 267 160
Viburnum dentatum L. var. dentatum Rough Arrowwood 200 4600 1440
Viburnum lentago L. Nannyberry 480 5040
Totals 800 1371 40,733 61,480 12,880 35,960
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
147
Table 4. Importance values (IV, max = 100) for large tree (LT, >10 cm dbh) and small tree (ST, 2.5 cm < dbh < 10 cm) strata on 6 transects in Abes Run
wetland, Canaan Valley State Park, WV, 2002. 1 cm = 0.4 in.
T1 T2 T3 T4 T5 T6
Species Common name ST LT ST LT ST LT ST LT ST LT ST LT
Abies balsamea Balsam Fir 10 7 6 9 36 20 22 20
Acer rubrum Red Maple 4 3 5 4 8 6 5 4
Acer pensylvanicum L. Striped Maple 1
Acer spicatum Lam. Mountain Maple 3
Amelanchier laevis Smooth Serviceberry 2 16
Betula alleghaniensis Yellow Birch 14 62 43 57 37 19 29 34 9 18 15
Crataegus punctata Dotted Hawthorn 2
Fraxinus nigra. Black Ash 16 23 44 33 14 53 13
Picea rubens Red Spruce 67 2 100 3 15 3 9 14
Prunus serotina Black Cherry 2 1 0
Sorbus americana Marsh. Mountain-ash 2
Salix discolor Pussy Willow 2
Tsuga canadensis Eastern Hemlock 19 31 57 12 30 11 22 9 12 23 32
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
148
silty loam-silty clay loam layer that had been deposited upstream of the beaver
dam was 8 inches (20 cm) (Fig. 2). Red parent material, classified as Mauch
Chunk, underlay the A and B horizons (Fig. 2). Average depth to groundwater
during the 2002 growing season was 5.5 in (14 cm). Soils were saturated for
approximately 86% of the growing season. In contrast to upstream transects,
we observed no standing water along this transect during this time period
(Fig. 3). Transect 1 had the lowest bryophyte coverage (8.6%) and the most
bare ground (25.7%) of the 6 transects. We recorded 43 plant species in the
sample subplots, and an additional 45 species outside the plots. In total, 29
species were grasses or sedges. Shrub richness and total density were the
lowest we recorded for the six transects. Ilex verticillata (Winterberry) and
Rhododendron maximum (Great Laurel) were the only true shrubs present; of
the large tree seedlings, only Tsuga canadensis (Eastern Hemlock) was present
in appreciable numbers. Mean C and FQI values were 5.1 and 31.7, respectively,
the lowest of the six transects.
Table 5. Bryophyte species recorded on 6 transects at Abes Run wetland, Canaan Valley State Park,
WV, 2001.
Species Common name
Mosses
Aulacomnium palustre (Hedw.) Schwaegr. Swamp Ribbed Moss
Brotherella recurvans (Michx.) Felish. Shiny Fern Moss
Callicladium haldanianum (Grev.) Crum Pretty Branch Moss
Climacium americanum Brid. American Tree Moss
Dicranodontium denudatum (Brid.) Britt. in Williams Naked Windblown Moss
Dicranum fuscescens Turner Dusky Fork Moss
Dicranum montanum Hedw. Mountain Fork Moss
Dicranum scoparium Hedw. Broom Fork Moss
Hypnum imponens Hedw. Flat Fern Moss
Hypnum linbergii Mitt. Seepy Fern Moss
Leucobryum albidum (Brid. ex. P. Beauv.) Lindb. Small White Cushion Moss
Leucobryum glaucum Hedw. Common White Cushion Moss
Loeskeobryum (Hylocomium) brevirostre (Brid.) Fleish. in Broth. Pinched Mountain Moss
Plagiomnium cuspidatum (Hedw.) T.J. Kop. Common Woodsy Mnium
Polytrichum commune Hedw. Common Hair Cap Moss
Polytrichum juniperinum Hedw. Juniper Hair Cap Moss
Polytrichum pallidisetum Funck Mountain Hair Cap Moss
Pylaisiadelpha tenuirostris (Bruch & Schimp. ex. Sull) W.R. Buck Slender Fern Moss
Rhytidiadelphys triquestros (Hedw.) Warnst. Common Shaggy Moss
Sphagnum fallax (H. Klinggr.) H. Klinggr. Sharp Longleaf Peatmoss
Sphagnum palustre L. Common Spoon Peatmoss
Tetraphis pellucida Hedw. Four Tooth Moss
Thuidium delicatulum (Hedw.) Schimp. in B.S.G. Delicate Fern Moss
Liverworts
Bazzania trilobata (L.) Gray Common Bazzania
Cephalozia lunulifolia (Dumort.) Dumort. Slim Crescent Liverwort
Lophocolea heterophylla (Schrad.) Dumort. Variable Mailpouch Liverwort
Nowellia curvifolia (Dicks.) Mitt. Wood-rust Liverwort
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
149
Tree stumps were scattered throughout the transect, but live trees were mostly
limited to the edge of the study area. Betula alleghaniensis (Yellow Birch) and
Eastern Hemlock were the most common large-tree species. Red Spruce, the most
abundant species in the small tree and sapling strata, first became established in the
Figure 2. Soil-horizon depth for center-sampling location of 6 transects, Abes Run wetland,
Canaan Valley State Park.
Figure 3. Average growing-season depth (cm) to water table for the center well of 6 transects
(T1–T6) at Abes Run wetland, Canaan Valley State Park. A negative value indicates
water table is below the surface.
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
150
1980s. The most abundant herbs were Carex atlantica (Prickly Bog Sedge), Leersia
oryzoides (Rice Cutgrass), and Scheonoplectus tabernaemontani (Great Bulrush).
Transect 2
Vegetation within transect 2 had a Cowardin classification of PEM1 and was
similar in structure to transect 1, although forbs such as Euthamia graminifolia
(Grass-leaved Goldenrod) and ferns, including Dennstaedtia punctilobula (Hayscented
Fern), Intermediate Fern, and Osmunda cinnamomea (Cinnamon Fern),
were more abundant than grasses and sedges. Mean C and FQI of 5.1 and 33.5,
respectively, were also comparable to the values for transect 1. Approximately
7.9 in (20 cm) of soil organic matter had accumulated along the forested edges
of this transect, but there was none in the center (Fig. 2). A gleyed layer of silty
clay loam occurred at a depth of ~9 in (22 cm; Fig. 2) . During the 2002 growing
season, the water table remained an average of 8 in (20 cm) below the surface;
soils were saturated for roughly half that time period (Fig 3).
As with Transect 1, this area was inundated by Castor canadensis Kuhl.
(North American Beaver) in the 1970s and Red Spruce stumps were still present.
Live Red Spruces were concentrated along this transect’s upland margins. Ringwidth
analyses showed these stems to average 20 y old. The shrub stratum was
relatively depauperate, but Rubus allegheniensis (Allegheny Blackberry) and
Acer rubrum (Red Maple) seedlings were present.
Transect 3
The vegetation of transect 3, which was upstream of the 1970s-era beaver
pond, had a Cowardin classification of palustrine forested mixed (PFO8). This
transect, as well as transects 4, 5, and 6, were compositionally and structurally
more diverse than transects 1 and 2. The main differences can be attributed to:
(1) a well-developed shrub stratum; (2) broken, low-density cover in the tree and
small-tree strata; (3) a 39-in (100-cm)-thick organic layer (Fig. 2); and (4) a high
degree of hydrologic variation along a gradient of soil type and depth from the
upland boundaries to the transect center. Structural diversity was reflected in the
wetland-quality assessment. Mean C and FQI values were 5.8 and 43.3, respectively.
Standing water was present for 43% of the growing season, and average
depth to groundwater was only 2.4 in (6 cm) (Fig. 3). Surface-water movement
took the form of overland sheet flow with few defined stream chan nels.
In the herbaceous stratum, only the following 3 species exceeded an average
cover-value of 10%: Caltha palustris (Marsh Marigold), Golden Ragwort, and
Fowl Mannagrass. We also observed 3 rare and calcium-tolerant species on this
transect—Jacob’s ladder, Glade Spurge, and Black Ash.
Shrub density was approximately 16,500 stems/ac (41,000 stems/ha), of which
Alder-leaved Buckthorn (11,540/ac [28,733/ha]) and Winterberry (10,333/ha
[4,150/ac]) were the primary components. The high stem-density of the latter species
may have been partially due to sprouting associated with intensive browsing by
Odocoileus virginianus Zimmerman (White-tailed Deer). The large- and small-tree
strata also showed relatively high stem densities of 150 and 112 trees/ac (396 and
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
151
279 trees/ha), respectively, yet most individuals were small in both diameter and
crown size. Thus, these strata provided only partial shade to the understory. Despite
high tree densities, basal area totaled only 52.6 ft2/ac (12.1 m2/ha).
Although the large- and small-tree strata were dominated by deciduous species,
such as Yellow Birch and Black Ash, coniferous species such as Eastern Hemlock,
Balsam Fir, and Red Spruce were also present. Establishment dates varied by species.
We determined that one Eastern Hemlock tree became established in 1849,
before the start of turn-of-the-century logging on the site. Balsam Fir became
established in the 1940s and 1950s. The Speckled Alders on this transect were the
oldest detected in the Abes Run study area, having become established in 1968.
Transect 4
Also classified as PFO8, the vegetation within transect 4 was compositionally
and structurally similar to what we documented in transect 3. Mean C and
FQI values were 5.7 and 45.2, respectively. Groundwater remained within 1.6
in (4 cm) of the wetland surface through early July; soils were saturated for the
entire growing season. Total bryophyte cover, primarily Sphagnum spp., averaged
22%, the highest recorded on the 6 transects. Depth of organic soil at the
center of this transect was 37 in (95 cm). The overstory was characterized by a
broken large-tree canopy above a very dense shrub-layer composed primarily of
Speckled Alder, Winterberry, Alder-leaved Buckthorn, and Viburnum dentatum
(Rough Arrowwood). Although total shrub density (24,500 stems/ac [61,400
stems/ha]) was the highest of the 6 transects, heavy browse of Winterberry resulted
in a broken shrub canopy and alternating patches of shade and sunlight
on the wetland floor. Thus, both shade-tolerant Glyceria melicaria (Mannagrass)
and shade-intolerant Fowl Mannagrass and Glyceria canadensis (Rattlesnake
Mannagrass) occurred here. As a result of this habitat variation, diversity in the
herbaceous stratum was high. Species diversity and evenness indices were 3.33
and 0.88, respectively, and total herb-cover was 96%. We recorded a total of 86
herbaceous species on this transect; the herbaceous stratum was dominated by
Marsh Marigold, Fowl Mannagrass, and Golden Ragwort.
The overstory in transect 4 resembled that of transect 3, with Black Ash, Yellow
Birch, and Eastern Hemlock as the dominant tree species, and Balsam Fir
and Red Maple as lesser components. Red Spruce was important in the small-tree
and sapling stratum (112 saplings/ac [280 saplings/ha]). The trees we sampled
on transect 4 were the oldest we documented in the wetland, with 3 trees predating
the turn-of-the-century logging. Two Black Ash trees became established in
1811 and 1893, respectively, and the earliest ring for one Eastern Hemlock (dbh
= 7.1 in [17.8 cm]) was inferred as dating from 1759. Other Balsam Fir and Red
Spruce individuals were recruited in the 1930s and 1950s, respectively. The oldest
Speckled Alders dated to the 1970s and 1980s.
Transect 5
The vegetation of transect 5 was also classified as PFO8. Soils were saturated
during the entire growing season, with an overall mean depth of the water table of
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
152
4 in (10.2 cm), though it fell to 9.8 in (25 cm) in early August. Shrub density (4819
stems/ac [12,000 stems/ha]) was lower than on transects 3 and 4, principally due
to higher tree-density and lower density of Alder-leaved Buckthorn. The lower
density may be associated with the absence of an organic horizon in the transect’s
center. As a result of lower shrub density, the understory was highly illuminated.
Thus, shade-tolerant Mannagrass was an important component of transects 3 and 4,
but it was replaced on transect 5 by shade-intolerant Rice Cutgrass.
Similar to conditions on transect 4, the overstory on transect 5 was broken and
low-density with Balsam Fir, Black Ash, and Eastern Hemlock as the dominant
species. Both Black Ash and Balsam Fir became established during 1940–1970.
However, Red Spruce was present only as sapling- and tall seedling-sized individuals.
Impatiens capensis (Jewelweed), Carex bromoides (Brome-like Sedge),
Carex gynandra (Nodding Sedge), and Fowl Mannagrass were the most abundant
herbaceous species.
Transect 6
Transect 6 supported two types of vegetation—PFO4 (palustrine forested
evergreen) and PFO8—and closely resembled transects 3 and 4. However, this
was the most diverse transect sampled (H' = 3.35). The organic horizon was
~30 in (77 cm) deep in the middle of this transect; depth to groundwater averaged
4 in (10 cm) during the growing season. Eight and 10 species occurred in
the large and small-tree strata, respectively, although total large and small-tree
density and basal-area values were not appreciably different from those of transects
3, 4, and 5. We recorded 12 shrub species on transect 6; 4 of these—Salix
discolor (Pussy Willow), Spiraea alba (Meadowsweet), Sambucus nigra ssp.
canadensis (Black Elderberry), and Viburnum lentago (Nannyberry)—occurred
only on this transect.
We found 61 herbaceous species in the subplots, and noted an additional 35
species in the walk-around. Onoclea sensibilis (Sensitive Fern), Marsh Marigold,
Golden Ragwort, and Lysimachia ciliata (Fringed Loosestrife) were the most
abundant herbs. Geum rivale (Purple Avens), Jacob’s Ladder, Swamp Saxifrage,
Listera smallii (Kidney-leaf Twayblade), Alder-leaved Buckthorn, and Black
Ash occurred here, all of which had C-values of 9. Thus, this transect’s FQI value
was 48.2, highest of all transects. The species diversity index was 3.56, also highest
of the 6 transects, and the maximum herbaceous cover-value for any single
species was 8.8%, the lowest of the transects.
The oldest trees were a Red Spruce and an Eastern Hemlock, established in
1830 and 1909, respectively; however, most trees established during 1930–1960.
Changes in vegetation cover type, 1945–1997.
A rank-comparison of 1945 and 1997 vegetative-cover classes revealed no
significant differences (Kruskall-Wallis test, χ2 = 1.06, P = 0.180; Table 6).
Prior to the logging era of the early 1900s, spruce–Eastern Hemlock was the
predominant vegetative cover on the Valley’s floor, with Red Spruce and
northern hardwood forests more important on the side slopes (Fortney 1975).
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
153
However, by 1945, Red Spruce was limited to mountain ridgetops and swamp
forests such as those along Abes Run (Fortney and Rentch 2003). In the Abes
Run watershed, upland mixed (UFO8) and deciduous (UFO1) forests showed
an increase between 1945 and 1997, however, the coniferous component of the
mixed-deciduous forest consisted of more Eastern Hemlock than Red Spruce
in 1997. Upland coniferous forests (UFO4) were not observed in the 1945
photograph, and were noted only in 1997 (0.49 ac [0.2 ha]). Over the 52-year
period, there was also a 30% (83 ac [33.4 ha]) decline in upland herbaceous
cover (UHU), and a comparable increase of both upland scrub-shrub (USS1)
and upland forested-cover types in the watershed. These results conform to
the overall successional trends in Canaan Valley noted by Fortney and Rentch
(2003). These findings reflect the secondary succession of abandoned fields
to shrub thickets, principally Hypericum densiflorum (St. Johnswort) in more
poorly drained areas, and Vaccinium angustifolium (Lowbush Blueberry) and
Crataegus punctata (Dotted Hawthorn) in better-drained areas.
In the Abes Run watershed, coniferous swamp forests (PFO4) declined by
more than 50% (17.7 ac [7.1 ha]) between 1945 and 1997 (Table 6). During
this period, there were also increases in wet-graminoid (PEM1), scrub-shrub
(PSS1), and wet mixed forest (PFO8) cover types. The wet-graminoid increase
was concentrated in old beaver-impacted areas in the lower end of the study area
(transects 1 and 2), and the scrub-shrub increase occurred primarily in the uppermost
reaches of the wetland (transects 5 and 6), where relatively young colonies
of Pussy Willow and Speckled Alder became established in late 1980s.
Discussion
Although extirpated in the 1850s, the North American Beaver was re-introduced
into the Valley around 1936 (Swank 1949) and had noticeable impacts on
the area’s hydrology and vegetation. Beaver ponds create high-quality wetland
Table 6. Changes in vegetative cover-class for Abes Run watershed, 1945–1997. PEM1, PFO4,
PFO8, and PSS1 are all palustrine habitats; PEM1 vegetation is emergent and persistent; PSS1
vegetation is deciduous.
1945 1997
Code Vegetative Cover Class Area (ac) % Area (ac) %
PEM1 Wet-herbaceous 3.2 0.9 15.4 4.2
PFO4 Wet-coniferous forest 32.6 8.9 14.9 4.1
PFO8 Wet-mixed forest 26.9 7.3 37.9 10.2
PSS1 Wet-scrub-shrub - - 14.4 3.9
UHU Upland-herbaceous 230.6 62.6 14.4 39.9
UFO1 Upland-deciduous forest 57.5 15.6 75.7 20.5
UFO4 Upland-coniferous forest - - 0.5 0.1
UFO8 Upland-mixed forest 17.4 4.8 27.9 7.5
USS1 Upland-deciduous shrub - - 30.4 8.2
UUV Unvegetated - - 4.5 1.2
Totals (wetland) 62.8 17.0 82.7 22.0
Totals (watershed) 368.3 100.0 369.1 100.0
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
154
habitats that differ in species composition and structure from areas immediately
outside the impoundments. For example, Bonner et al. (2009) found that although
the oldest ponds supported twice as many rare plant species as younger ones,
younger ponds were more species diverse than older ones.
In Abes Run, changes in vegetative-cover class from 1945 to 1997 were associated
with (1) cutting and damming activities by Beaver, particularly in the
coniferous swamp forests in the lower end of the study area, and (2) gradual conversion
of inundated areas to wet graminoid meadows as dams were abandoned
or breached and their ponds dried. With persistent inundation, tree mortality may
be rapid. Swank (1949) reported that the length of time required to water-kill
trees is 1–2 years for Eastern Hemlock, Red Spruce, and Yellow Birch, and 1–3
years for Balsam Fir.
Two additional stressors have contributed to the decline of swamp forests,
particularly those with a Balsam Fir component. Adelges piceae Ratzeburg (Balsam
Woolly Adelgid) is an invasive species introduced from Europe around 1900
(Ragenovich and Mitchell 2006). It constitutes a serious threat to both Abies fraseri
(Pursh) Poir. (Fraser Fir) and Balsam Fir in the eastern US. The insect attacks trees
of all sizes, although seed-bearing and mature overstory trees appear to be most
susceptible (Ragenovich and Mitchell 2006). Although we did not document the
degree of infestation, we observed that many firs showed evidence of being attacked
or killed by Balsam Woolly Adelgid. The second stressor is the Valley’s White-tailed
Deer population, which has been among the highest in the state from the 1950s to the
present (Michael 1992), with ostensible impacts such as sharp browse-lines. Michael
(1992) noted that prior to 1950, White-tailed Deer apparently had little impact
on Balsam Fir regeneration. However, as hunting became restricted or prohibited on
large tracts of private and public land, the deer population increased substantially,
reaching 111–148 deer/mi2 (287–384 deer/km2) in 2005 (Cherefko et al. 2014). In
view of observed high browse-pressure, Michael (1992) predicted that Balsam Fir
would eventually be replaced by Red Spruce in the Valley.
White-tailed Deer herbivory constitutes an intermediate-level disturbance
that can both increase and decrease species diversity (see Russell et al. 2001).
For example, the low levels of Balsam Fir seedlings (e.g., 16 seedlings/acre [40
seedlings/ha] observed on transect 6 may be attributable to heavy White-tailed
Deer pressure because Balsam Fir is a desirable browse species. White-tailed Deer
also browse rare species (Gregg 2004) such as Showy Lady’s Slipper and Highbush
Cranberry. Populations of both have been severely reduced (Gregg 2004).
Conversely, heavy browse of Winterberry, which was common in transects 3–6,
appears to have maintained or even increased species diversity by reducing height
and crown size and allowing more light to penetrate to the forest floor where several
herbaceous species have now established.
The distinctiveness of the Valley’s wetland habitats has been well documented
(e.g., Allard and Leonard 1952; Fortney 1975, 1993; and numerous papers in this
Special Issue). Among the principal features noted are a complex juxtaposition
of upland and wetland habitats, the presence of plant communities at different
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
155
successional stages, the presence of a distinctly boreal flora, the mountain-valley
frost-pocket effect on microclimate, and the impacts of anthropogenic activities
on habitats and biota, including logging, fires, and farming (Fortney and Rentch
2003). All of these Valley-wide features are evident along Abes Run, and contribute
to a remarkably rich flora that exhibits a high degree of naturalness in species
composition and structure, as measured by mean C and FQI.
Additional features that may contribute to the high species and community
diversity along Abes Run include: (1) a species-rich yet non-continuous tree and
shrub structure that results in a variable light regime on the wetland floor, which
provides habitat to both shade-tolerant and shade-intolerant species; (2) a variable
hydrologic regime where the depth to the water table varies considerably
both temporally and over short distances from the wetland edge to the center;
(3) the influence of a limestone substrate (Chambers et al. 2015 [this issue], Fortney
et al. 2015 [this issue], Matchen 2015 [this issue], Sencindiver et al. 2015
[this issue]) that provides sufficient nutrients for both acidophilic and calciophilic
plants; and (4) the apparent absence of destructive slash fires that affected
the rest of the Valley (Adams and Kochenderfer 2015 [this issue], Carvell 2015
[this issue]), as evidenced by the presence of cohorts of trees that predate turnof-
the-century logging.
Our comparison of 1945 and 1997 aerial photography yielded an estimate
of the vegetation changes that occurred in Abes Run over those 52 years. In the
uplands, successional patterns generally followed conventional autoecological
models (e.g., Smith 1996) in which herbaceous-dominated communities are replaced
by shrubs that are, in turn, replaced by forests. In the Abes Run wetland,
vegetative changes were less linear or predictable. Environmental factors such as
hydrology (the extent and duration of saturation and/or flooding) and disturbances
(logging, Beaver, White-tailed Deer, pathogens) have, at times, overshadowed
biotic factors, and diverted the expected successional course.
Conclusions
This study provides baseline data for a small, botanically unique wetland
complex that supports many rare plant species and several rare wetland plant
communities. Small, isolated, and patchy headwater wetlands such as Abes
Run are a significant resource because they serve as refugia for a host of wetland-
obligate plants (Byers et al. 2007). Results from our aerial photographic
assessment of vegetation changes over 52 years suggest that this wetland has
shown a high degree of resiliency despite several episodes of natural and anthropogenic
disturbance. At present, principal stress-factors include plant pests,
herbivory by White-tailed Deer, and alteration of the hydrology by North American
Beaver. Some stressors, like Mprth American Beaver, White-tailed Deer,
and changes in land-use and land-cover may be relatively manageable at the
local level, while others, such as climate change, acid deposition, and introductions
of exotic pests and pathogens are less amenable to local control. Efforts
by park managers to minimize disturbances to the hydrology of Abes Run are
critical for maintaining the integrity of this special resource.
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
156
Acknowledgments
The authors thank James Gorman, Sam Lamont, and Susan Studlar for soils, hydrologic,
and bryophyte data, respectively, and the Division of Forestry and Natural Resources
at West Virginia University. We also thank John Northeimer of Canaan Valley State Park for
providing water-table data. Partial funding was provided by a McIntire-Stennis grant and
by a grant from the Canaan Valley Institute and the US Department of Agriculture.
Literature Cited
Adams, M.B., and J.N. Kochenderfer. 2015. The Fernow Experimental Forest and
the Canaan Valley: A history of research. Southeastern Naturalist 14(Special Issue
7):433–440.
Allard, H.A., and E.C. Leonard. 1952. The Canaan and Stony River valleys of West Virginia,
their former magnificent spruce forests, their vegetation, and floristics today.
Castanea 17:1–60.
Bonner, J.L., J.T. Anderson, J.S. Rentch, and W.N. Grafton. 2009. Vegetative composition
and community structure associated with beaver ponds in Canaan Valley, West
Virginia, USA. Wetlands Ecology and Management 17:543–554.
Byers, E.A., J.P. Vanderhorst, and B.P. Streets. 2007. Classification and conservation
assessment of high-elevation wetland communities in the Allegheny Mountains of
West Virginia. West Virginia Natural Heritage Program, WVDRN, Elkins, WV. 192
pp. Available online at http://www.wvdnr.gov/Publications/PDFFiles/High%20Allegheny%
20Wetlands-web.pdf. Accessed 2 October 2014.
Carvell, K.L. 2013. An environmental history of Canaan Valley. Southeastern Naturalist
14(Special Issue 7):428–432.
Chambers, D.B., J.B. Wiley, and M.D. Kozar. 2015. Overview of hydrologic and geologic
investigations conducted in Canaan Valley, West Virginia. Southeastern Naturalist
14(Special Issue 7):87–102.
Cherefko, C., C. Fridley, J. Medsger, M. Woody, and J.T. Anderson. 2015. White-tailed
Deer and Balsam Woolly Adelgid Effects on Balsam Fir in Canaan Valley. Southeastern
Naturalist 14(Special Issue 7):218–231.
Core, E.L. 1966. The Vegetation of West Virginia. McClain Printing Company, Parsons,
WV. 215 pp.
Cowardin, L.M., V. Carter, F.C. Golet, and E.T. LaRoe. 1979. Classification of wetlands
and deepwater habitats of the United States. US Fish and Wildlife Service Publication.
FWS/OBS-79/31, Washington, DC. 131 pp.
Daubenmire, R. 1968. Plant Communities: A Textbook of Plant Synecology. Harper and
Row, New York, NY. 270 pp.
Fortney. R.H. 1975. The vegetation of Canaan Valley, West Virginia: A taxonomic and
ecological Study. Ph.D. Dissertation. West Virginia University, Morgantown, WV.
208 pp.
Fortney, R.H. 1993. Canaan Valley: An area of special interest. Pp. 47–65 In S.L. Stephenson
(Ed.). Upland Forests of West Virginia. McClain Printing Company, Parsons,
WV. 295 pp.
Fortney, R.H., and J.S. Rentch. 2003. Post-logging era plant successional trends and geospatial
vegetation patterns in Canaan Valley, West Virginia, 1945 to 1997. Castanea
68:317–334.
Fortney, R.H., S.L. Stephenson, and J.S. Rentch. 2015. Rare plant communities in Canaan
Valley, West Virginia. Southeastern Naturalist 14(Special Issue 7):121–135.
Southeastern Naturalist
J.S. Rentch, R.H. Fortney, J.T. Anderson, and W.N. Grafton
2015 Vol. 14, Special Issue 7
157
Gleason, H.A., and A. Cronquist. 1991. Manual of Vascular Plants of Northeastern
United States and Adjacent Canada. New York Botanical Garden, Bronx, NY. 910 pp.
Gregg, K.B. 2004. Recovery of Showy Lady’s Slipper (Cypredium reginae Walter) from
moderate and severe herbivory by White-tailed Deer (Odocoileus virginianus Zimmerman).
Natural Areas Journal 24:232–241.
Harmon, P.J., D. Ford-Werntz, and W. Grafton. 2006. Checklist and atlas of the vascular
flora of West Virginia. WV Division of Natural Resources, Wildlife Resources Section,
Elkins, WV. 381 pp.
Losche, C.K., and W.W. Beverage. 1967. Soil Survey of Tucker County and Part of
Northern Randolph County, West Virginia. US Department of Agriculture, Soil Conservation
Service; US Forest Service; and West Virginia Agricultural Experiment
Station. Washington, DC. 78 pp.
Matchen, D.L. 2015. The geology of Canaan Valley. Southeastern Naturalist 14(Special
Issue 7):7–17.
McCune, B., and M.J. Mefford. 1999. PC-ORD. Multivariate analysis of ecological data,
version 4.0 (computer software). MjM Software Design, Glenedon Beach, OR.
Michael, E.D. 1992. Impact of deer browsing on regeneration of Balsam Fir in Canaan
Valley, West Virginia. Northern Journal of Applied Forestry 9:89–90.
National Climate Data Center (NCDC), National Oceanographic and Atmospheric Administration.
2003. Available online at http://www1.ncdc.noaa.gov/pub/orders. Accessed
10 September 2002.
Pittillo, J.D. 1994. Appalachian bogs and implications of their vegetational history. Water,
Air, and Soil Pollution 77:333–348.
Ragenovich, I.R., and R.G. Mitchell. 2006. Balsam Woolly Adelgid. USDA Forest Service,
Forest Insect and Disease Leaflet, No. 1 18. Washington, DC. 11 pp.
Reed, P.B., Jr. 1988. National list of plant species that occur in wetlands: Northeast. US
Fish and Wildlife Service. Biological Report 88(24). 244 pp.
Rentch, J.S., and J.T. Anderson. 2006. A wetland floristic-quality index for West Virginia.
West Virginia Agricultural and Forestry Experiment Station Bulletin 2967. Morgantown,
WV. 65 pp.
Russell, F.L., D.B. Zippin, and N.L. Fowler. 2001. Effects of White-tailed Deer (Odocoileus
virginianus) on plants, plant populations, and communities: A review. American
Midland Naturalist 146:1–26.
Sencindiver, J., K. Thomas, and J. Teets. 2015. Soils of Canaan Valley and adjacent
mountains. Southeastern Naturalist 14(Special Issue 7):33–39.
Smith, R.L. 1996. Ecology and Field Biology. Harper and Row, New York, NY.
Stokes, M.A., and T.L. Smiley. 1968. An Introduction to Tree-ring Dating. University of
Arizona Press, Tuscon, AZ. 73 pp.
Strausbaugh, P.D., and E.L. Core. 1977. Flora of West Virginia, 2nd Edition. Seneca
Books, Grantsville, WV. 1079 pp.
Studlar, S.M., S.L. Stephenson, and P.J. Harmon. 2002. Annotated checklist of the hornworts,
liverworts, and mosses of West Virginia. WV Division of Natural Resources,
Wildlife Resources Section. Wildlife Resources Technical Document 02-3. 81 pp.
Swank, W.C. 1949. Beaver ecology and management in West Virginia. Conservation
Commission of Game Management. Bulletin Number 1, Charleston, WV.
US Environmental Protecton Agency (USEPA). 1992. Land-cover classification for
Canaan Valley, West Virginia. Environmental Photographic Interpretation Center
(EPIC), Warrenton, VA.
