Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
218
Canaan Valley & Environs
2015 Southeastern Naturalist 14(Special Issue 7):218–231
White-tailed Deer and Balsam Woolly Adelgid Effects on
Balsam Fir in Canaan Valley
Chad Cherefko1,2, Collin Fridley1, Jason Medsger1, Melvin Woody1,
and James T. Anderson1,*
Abstract - Abies balsamea (Balsam Fir) was historically abundant in parts of West
Virginia, but it was drastically reduced by extensive logging around the turn of the
19th–20th centuries. More recently, intense herbivory by Odocoileus virginianus
(White-tailed Deer) and an infestation of Adelges piceae (Balsam Woolly Adelgid),
among other possible factors, have caused Balsam Fir to decline in the region. Understanding
the impacts of White-tailed Deer and Balsam Woolly Adelgid is important
for restoring Balsam Fir in Canaan Valley. On the Freeland Tract of the Canaan Valley
National Wildlife Refuge, we surveyed the intensity of browsing on Balsam Fir and
estimated deer population levels, while Refuge personnel assessed the intensity of the
adelgid infestation. Even though estimates of deer density were significantly greater
during 1999–2000 than in 2001–2002, the percent of buds browsed was similar during
the two periods. During 2001–2002, browsing was more intense on Balsam Fir trees
that were outside than on trees inside an exclosure. Deer had minimal to moderate
impact on mature trees, but in many cases, they completely browsed all of the buds
on trees <3.3 ft (1 m) tall. The proportion of trees infested by Balsam Woolly Adelgid
rose by 17.4%—from 51.3% in 2000 to 68.7% in 2002. The average diameter at
breast height of Balsam Firs heavily infested by adelgids was significantly larger than
of those trees classified as moderate, light, or not infested. The Balsam Woolly Adelgid
is of greater conservation concern than White-tailed Deer because some of the
trees tallied in the first phase of our survey were already dead. Restoration efforts that
involve the planting of seedlings should consider the impacts of deer on seedlings and
the impacts of adelgids on mature trees.
Introduction
Located in northeastern West Virginia, Canaan Valley (hereafter, the Valley)
harbors diverse floral and faunal communities in large wetlands that are otherwise
uncommon throughout the Appalachian region. The Valley’s climate is
typical of higher latitudes, which in part has allowed the persistence of northern
species (Fortney 1975). One such plant is Abies balsamea (L.) Mill. (Balsam Fir,
hereafter “Fir”), which in West Virginia is commonly found in damp woods and
wetlands >3218 ft (975 m) above sea level (Michael 1992). Its local presence is
interpreted as a relic of southward dispersal during the Pleistocene glaciations
(Core 1966).
1Division of Forestry and Natural Resources, West Virginia University, PO Box 6125,
Morgantown, WV 26506. 2Current address - USDA Natural Resources Conservation Service,
687 Pittstown Road, Frenchtown, NJ 08825. *Corresponding author - jim.anderson@
mail.wvu.edu.
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
219
Fir was once locally abundant in parts of West Virginia, but extensive logging
during 1885–1924 and subsequent fires devastated many stands (Cl arkson 1964,
Fansler 1962). After logging ended, intense fires burned the remaining trees and
the organic soils, leaving scattered stumps and rotting logs perched on exposed
rocks (Clarkson 1964, Fortney 1975). Fir is valued as a timber species in northern
latitudes, where it is cut for pulpwood and Christmas trees (Bakuzis and Hansen
1965). In the Valley, however, natural stands of Fir have intrinsic and scientific
values (Michael 1992), due in part to its membership in a relict ecosystem. Fir
is rare this far south; in West Virginia it occurs only in Grant, Tucker, Randolph,
and Pocahontas counties (B.R. McDonald, Natural Heritage Program, Elkins,
WV, pers. comm.; Stephenson and Adams 1986).
Unfortunately, Fir is threatened by several stressors. Although potential
threats include Castor canadensis (Kuhl) (North American Beaver) and the
atmospheric deposition of pollutants, two issues of greater significance are
intense browsing by Odocoileus virginianus Zimmerman (White-tailed Deer,
hereafter “Deer”) and infestation by the Adelges piceae (Ratzeburg) (Balsam
Woolly Adelgid, hereafter “Adelgid”). Fir is a preferred winter browse species
of Deer (Chouinard and Filion 2001, Leopold et al. 1998, Stephenson 1993). The
negative effects of browsing by Deer on tree regeneration are well known (Jones
1984, Michael 1992). In much of Central Appalachians, one of the most notable
concerns about wildlife has been the overabundance of Deer and its effects on
native plant communities (Stromayer and Warren 1997), but little is known about
the specific impacts of Deer on Fir in West Virginia.
The Adelgid, an exotic pest first recorded in North America in 1908, can be
identified by the white wool-like balls of hair that are apparent on the bark of
infested trees (Bakuzis and Hansen 1965). This sap-sucking insect has been reported
to disperse from poorly drained sites, which are characteristic Fir habitat,
and the Adelgid can kill its host within 2–3 y after the initial infestation (Bakuzis
and Hansen 1965). The 3 objectives of this study were to determine the number of
Deer using Fir stands, quantify the browse intensity of Deer on Fir, and evaluate
the impacts of Adelgids on Fir.
Study Area
We conducted this study in the Valley, a highland basin at an elevation of
3218 feet (975 m). The Valley hosts one of the East’s largest shrub-swamp forests
(10325 ac [4130 ha]; Fortney 1975). Weedfall and Dickerson (1965) classified
the Valley’s climate as cold humid, featuring cool summers, moderate to severe
winters, and relatively high precipitation. The Valley’s mean annual precipitation
of 54 in (137 cm) and mean annual snowfall of 120 in (305 cm) are higher than
in surrounding areas. Its average temperature is 46 °F (7.5 °C), with a 92-day
frost-free growing season (Weedfall and Dickerson 1965).
Our study area was located on the Freeland Tract of the Canaan Valley National
Wildlife Refuge (CVNWR; Fig. 1) in the southeastern end of the Valley. In
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
220
1994, the Freeland Tract, which includes 87 ac (34.8 ha) of shrub-swamp forest
and meadows, was the first piece of land purchased for the CVNWR. Most of the
tract (70 ac [28 ha]) was formerly used for hay production (Warren 2001). The
Freeland Tract’s floor is mainly Atkins silt loam, which is a poorly drained soil
of bottomlands (USDA 1967). We sampled two areas within the Freeland Tract:
(1) beaver stand—a small, isolated, and moderately dense 0.35-ac (0.14-ha) Fir
stand with a small stream running through its eastern edge; and (2) main stand—a
dense 5.9-ac (2.35-ha) Fir stand near the Freeland Tract’s north-central border.
We divided main stand into two sampling areas separated by a small stream.
Both study stands included minor components of Tsuga canadensis (L.) Carriere
(Eastern Hemlock), Picea rubens Sarg. (Red Spruce), and Betula alleghaniensis
Britt. (Yellow Birch).
Figure 1. The Freeland Tract study site located in Canaan Valley National Wildlife Refuge
in the southeastern end of the Valley, Tucker County, WV, 1999–2002.
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
221
Methods
Field techniques
We conducted pellet-group or fecal-group counts to estimate relative Deer
abundance (Neff 1968) during November 1999–April 2000 and October 2001–
March 2002. We delineated 15 randomly sited (Ratti and Garton 1996) 16.5 x
16.5 ft (5 x 5 m) plots in 1999–2000 and 20 plots in 2001–2002. Prior to the first
search, we cleared all plots of pellet groups by crushing them with our boots
or removing them from the plot (Neff 1968). We made a total of 5 systematic
searches during the 1999–2000 season and 8 searches in 2001–2002. To prevent
pellet groups from being counted in future visits, we tallied and then removed all
pellet groups from the plots following each search (Neff 1968, Ratti and Garton
1996). During the 2001–2002 season, we conducted 8 searches during 11 visits
because complete or partial snow cover prevented accurate counts. To improve
the accuracy of the 2001–2002 Deer-use data, we surveyed at two-week intervals
during the season. To estimate relative Deer abundance, we used the equation, t =
1 / na’* y (Neff 1968), in which t is the number of pellet groups per unit area, n is
the number of plots, a is the area of 1 plot, and y is the sum of the pellet groups
in all plots. We assumed a defecation rate for a winter herd on good range to be
15 pellet groups per day (Neff 1968).
To measure browse intensity, we randomly selected 15 Fir trees for the browse
survey during both sampling periods—1999–2000 and 2001–2002. During the
first time block, 4 of the selected trees were growing in the beaver stand, 3 of
which remained in the latter period. All other trees sampled were in the main
stand. During the 1999–2000 period, we also sampled 2 trees within a fenced
Deer exclosure in the main stand.
During the 1999–2000 sampling period, we divided each tree into four quadrants
(Aldous 1944). For one randomly selected quadrant of each tree, unless
a whole-tree count was needed due to small tree size (less than 30 buds), we recorded
the number of buds present for that quadrant up to the 6-ft (1.83-m) browse line
(Doenier et al. 1997). The decrease in bud number through the browse season
represented the number of buds browsed (Aldous 1944, Doenier et al. 1997).
While using the method described above, we sometimes questioned whether
part of a tree branch was in or out of the quadrant or was above or below the
browse line, so we changed the procedure for 2001–2002. To reduce error, we
marked and counted buds on two branches within the browse line on each sample
tree, except when whole-tree counts were needed due to tree size. In this way, we
avoided debates about whether part of a tree branch was in vs. out of the quadrant
or above vs. below the browse line.
We completed 3 browse tallies during 1999–2000 and 9 tallies during 2001–
2002. Lateral buds expanded throughout the winter, so we had difficulty determining
the actual percent of buds that had been browsed between survey periods.
Therefore, we took the difference in the number of buds between the previous
and latter survey dates. If the number of buds increased due to bud re-growth or
stayed the same, zero percent of the buds were recorded as having been browsed.
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
222
If the number declined, it was recorded as a percentage of the total buds counted
for that tree. This difference provided a conservative estimate of the percentage
of buds browsed.
To assess Adelgid infestation levels on Fir, CVNWR staff studied 100 Firs in
the main stand and 50 in the beaver stand in September 2000 and August 2002. To
find the woolly clusters indicative of Adelgids, they used a hand lens to carefully
inspect the bark, twigs, and branches of each tree. Infestation level was reported
as none (zero clusters), light (1–5 clusters per tree), moderate (6–49 clusters per
tree), or heavy (50 or more clusters per tree) (K.K. Sturm, US Fish and Wildlife
Service, CVNWR, Davis, WV, unpubl. data). They also recorded the diameter at
breast height (DBH) for each tree surveyed. In 2002, samplers also measured the
DBH of dead Fir trees.
To determine species, trees per acre, total height, and basal area, we completed
a point-sampling cruise (Smith et al. 1997) on the main stand and a 100% tally
of the smaller beaver stand. On the main stand, we plotted 634-ft (192.2-m)-long
transects every 51.5 ft (15.6 m) along the tract’s western boundary for the length
of the stand (Smith et al. 1997). We laid out 0.01-acre (0.04-ha) plots every 206
ft (62.5 m) in beaver stand and 310 ft (93.8 m) in main stand (Avery and Burkhart
2002). To determine tree density, we tallied the number of trees per plot and extrapolated
that number into number/ac (ha). We calculated basal area from DBH.
Statistical analyses
For sets of continuous data, we evaluated normality using the Shapiro-Wilk
statistic and homogeneity of variances by plotting residuals (Cody and Smith
1991). Our data violated the assumptions of normality, so for 2001–2002, we
used the Kruskal-Wallis test (Sokal and Rohlf 1995) to compare average DBH
between dead trees and trees within each infestation category, Deer densities between
years, browse intensity between years, and browse intensity of Firs in and
out of the exclosure. We analyzed infestation rates of Firs by Adelgids between
years and among infestation categories using G-tests (Sokal and Rohlf 1995). We
set statistical significance at P < 0.05.
Results
Deer density estimates were greater for 1999–2000 (mean = 1.55 per ac [3.84/
ha], SE = 0.18 [0.44]) than during 2001–2002 (mean = 1.16 per ac [2.87/ha], SE =
0.11 [0.27]; χ2
1 = 7.15, P = 0.008). However, the percent of buds browsed was
similar (χ2
1 = 1.33, P = 0.249) between the former (mean = 20.06%, SE = 6.01)
and latter (mean = 26.09%, SE = 7.22) periods. During 2001–2002, the browsing
intensity on Fir was substantial outside the exclosure (mean = 26.09 buds per
quadrant, SE = 7.22) but completely absent inside the exclosure (mean = 0; χ2
1 =
4.88, P = 0.027).
The number of Fir trees infested by Adelgids increased by 17.4% from 2000
(51.3%) to 2002 (68.7%) (G1 = 9.44, P = 0.002). However, of the trees infested,
overall infestation levels were similar between years (G2 = 2.60, P = 0.2725;
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
223
Fig. 2). Infestation levels differed between the main and beaver stands during
both 2000 (G2 = 12.30, P = 0.002) and 2002 (G2 = 7.26, P = 0.027) (Fig. 3). During
both years, the main stand included a higher proportion of heavily infested
trees compared to the beaver stand. In 2000, the beaver stand also had a greater
proportion of trees classified with a light infestation level when compared to the
main stand. The average DBH of heavily infested Firs was greater than the DBH
of moderate, light, or non-infested trees (χ2
4 = 102.15, P < 0.001; Fig. 4). However,
the DBH of Firs that had likely been killed by Adelgids was similar to the
DBH of Firs classified with heavy or moderate infestation (Fig. 3).
In addition to Fir, the following 6 tree species grew in the survey plots: Eastern
Hemlock, Yellow Birch, Ulmus americana L. (American Elm), Acer rubrum
L. (Red Maple), Fagus grandifolia Ehrh. (American Beech), and Red Spruce. In
the main stand, Fir had the highest density (102 trees per ac [253/ha]). Eastern
Hemlock was second-most dense with 83 trees per ac (206/ha) (Table 1). In the
main stand, the density of all trees was 239 per ac (590/ha) and their basal area
was 51.4 ft2 per ac (11.8 m2/ha). In the main stand, Fir had the greatest basal
area (23.1 ft2 per acre [5.3 m2/ha]), and Eastern Hemlock was second with 17.6
ft2 per acre (4.05 m2/ha) (Table 1). The beaver stand had a Fir density of 846 trees
per ac (2090/ha) and a Red Spruce density of 140 trees per ac (347/ha) (Table 2).
Figure 2. Balsam Woolly Adelgid infestation rates on Balsam Fir, by category (light =
1–5 Adelgid masses observed, moderate = 6–49, heavy = 50 or more), for Freeland Tract,
Canaan Valley National Wildlife Refuge, 2000 and 2002.
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
224
Fir and Spruce had the greatest basal areas, with values of 26.6 ft2 per ac (6.1 m2/
ha) and 6.1 ft2 per ac (1.4 m2/ha), respectively (Table 2). In the beaver stand, the
total tree density was 1081 trees per acre (2670/ha), and total basal area was 38.8
ft2 per ac (8.9 m2/ha).
Discussion
Browsing by Deer and infestation by Adelgids negatively impacted Fir in the
Valley. From our data, we estimated Deer density to be 995 individuals per mi2
(384/km2) in 1999–2000 and 743 Deer per mi2 (287/km2) in 2001–2002. These
values clearly indicate that the Fir stand in the Freeland Tract was a high-use area
for Deer. We do not believe that our estimates of Deer abundance were true representations
of the actual population present on the CVNWR. Pellet surveys have
several inherent biases, including defecation rate, pellet loss, quadrat placement,
and observer bias (Langdon 2001). However, we believe our estimates indicate
that Fir stands were heavily used and that the use of the Freeland Tract declined
between the two survey periods. Between 1979 and 1991, Michael (1992) estimated
the Deer density was 243 Deer per mi2 (94/km2) on the Freeland Tract and
518 Deer per mi2 (200/km2) in the Fir stand. However, Michael (1992) used 25
Figure 3. Balsam Woolly Adelgid infestation rates on Balsam Fir between stands, by
category (light = 1–5 Adelgid masses observed, moderate = 6–49, heavy = 50 or more),
for Freeland Tract, Canaan Valley National Wildlife Refuge, 2000 and 2002.
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
225
pellet groups per day whereas we used only 15, indicating that population densities
were similar between his study and ours.
The browsing intensity by Deer on all Fir ranged from 20% to 26%, but
browse on individual trees outside of the exclosure ranged from 0.3% to 100%.
Although we did not include trees shorter than 6.6 ft (2 m) tall in our analyses, we
observed that trees shorter than 3.3 ft (1 m) always had 100% browsed branches.
In contrast, 2 trees protected by an exclosure were completely unbrowsed. Therefore,
Deer were impacting the growth of Fir in the Valley.
Fir-stem density was lower in areas with the highest Deer density (Michael
1992). Christmas-tree growers believed that tree growth was being severely
reduced by Deer browsing and rubbing (Atkins 1994). Chouinard and Filion
(2001) have also documented that high browse-intensity reduces vertical and
radial growth of conifers. In addition, browsing by Deer seems to alter stand
structure in favor of Red Spruce. In support of this hypothesis, Stromayer and
Warren (1997) suggested that Deer create alternate stable states of plant communities
in northern temperate forests by browsing on woody vegetation. They
stated that sustained, long-term suppression of regeneration contributes to local
extirpation of some tree species. This effect could prevent regeneration in sites
Figure 4. Average diameter (+ SE) at breast height (DBH) of Balsam Fir trees infested
with Balsam Woolly Adelgid on the Freeland Tract, Canaan Valley National Wildlife
Refuge, 2000 and 2002. Dead (presumably due to Balsam Woolly Adelgids), none = 0
Adelgid masses observed, light =1–5, moderate = 6–49, or heavy = 50 or more).
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
226
Table 1. Trees/ha and basal area (m2/ha) for 5 species of trees measured on the Main Stand (Freeland Tract) of Balsam Fir in the Valley, March 2002.
Diameter at breast height (DBH) classes are presented in cm with inches in parentheses. HEM = Eastern Hemlock, YB = Yellow Birch, BF = Balsam Fir,
AE = American Elm, and RM = Red Maple. Multiply by 0.41 to convert # trees/ha to # trees/ac, and by 0.23 to convert m2/ha to ft2/ac.
# trees/ha Basal area (m2/ha)
DBH Class HEM YB BF AE RM Total HEM YB BF AE RM Total
2.54 (1) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
5.08 (2) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
7.62 (3) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
10.16 (4) 50.39 28.41 24.45 0.00 0.00 103.25 0.44 0.22 0.22 0.00 0.00 0.89
12.70 (5) 37.54 40.26 67.43 18.03 0.00 163.27 0.44 0.44 0.89 0.22 0.00 2.00
15.24 (6) 39.52 0.00 81.76 0.00 0.00 121.28 0.67 0.00 1.56 0.00 0.00 2.22
17.78 (7) 33.10 18.28 42.48 0.00 0.00 93.86 0.89 0.44 1.11 0.00 0.00 2.45
20.32 (8) 36.31 6.67 14.82 0.00 0.00 57.55 1.11 0.22 0.44 0.00 0.00 1.78
22.86 (9) 6.18 9.88 6.18 0.00 0.00 23.96 0.22 0.44 0.22 0.00 0.00 0.89
25.40 (10) 0.00 4.69 9.14 0.00 0.00 13.83 0.00 0.22 0.44 0.00 0.00 0.67
27.94 (11) 0.00 0.00 3.95 0.00 0.00 3.95 0.00 0.00 0.22 0.00 0.00 0.22
30.48 (12) 3.21 0.00 2.96 0.00 0.00 6.18 0.22 0.00 0.22 0.00 0.00 0.44
33.02 (13) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
35.56 (14) 0.00 0.00 0.00 0.00 2.47 2.47 0.00 0.00 0.00 0.00 0.22 0.22
Total 206.25 108.19 253.18 18.03 2.47 589.59 4.00 2.00 5.34 0.22 0.22 11.78
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
227
Table 2. Trees/ha and basal area (m2/ha) for 5 species of trees measured on the Beaver Stand (Freeland Tract) of Balsam Fir in the Valley, March 2002.
Diameter at breast height (DBH) classes are presented in cm with inches in parentheses. HEM = Eastern Hemlock, YB = Yellow Birch, BF = Balsam Fir,
RS = Red Spruce, and AB = American Beech. Multiply by 0.41 to convert # trees/ha to # trees/ac, and by 0.23 to convert m2/ha to ft2/ac.
# trees/ha Basal area (m2/ha)
DBH Class HEM YB BF RS AB Total HEM YB BF RS AB Total
2.54 (1) 0.00 0.00 118.44 70.27 0.00 188.71 0.00 0.00 0.01 0.04 0.00 0.05
5.08 (2) 0.00 15.44 130.17 69.78 0.00 215.38 0.00 0.01 0.05 0.10 0.00 0.15
7.62 (3) 0.00 0.00 279.48 68.42 0.00 347.90 0.00 0.00 0.22 0.05 0.00 0.28
10.16 (4) 0.00 0.00 361.73 42.85 0.00 404.59 0.00 0.00 0.49 0.22 0.00 0.71
12.70 (5) 0.00 0.00 303.44 13.71 0.00 317.15 0.00 0.00 0.65 0.03 0.00 0.68
15.24 (6) 0.00 0.00 235.02 27.42 0.00 262.44 0.00 0.00 0.72 0.09 0.00 0.81
17.78 (7) 0.00 0.00 217.73 13.71 33.86 265.30 0.00 0.00 0.88 0.06 0.06 1.01
20.32 (8) 0.00 0.00 188.71 13.71 67.72 270.14 0.00 0.00 1.02 0.08 0.15 1.25
22.86 (9) 0.00 0.00 118.34 0.00 33.86 152.20 0.00 0.00 0.78 0.00 0.10 0.88
25.40 (10) 0.00 0.00 41.15 0.00 33.86 75.01 0.00 0.00 0.19 0.00 0.12 0.31
27.94 (11) 0.00 0.00 82.33 0.00 0.00 82.33 0.00 0.00 0.87 0.00 0.00 0.87
30.48 (12) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
33.02 (13) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
35.56 (14) 0.00 0.00 13.71 0.00 0.00 13.71 0.00 0.00 0.24 0.00 0.00 0.24
38.10 (15) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
40.64 (16) 0.00 0.00 0.00 0.00 33.86 33.86 0.00 0.00 0.00 0.00 0.33 0.33
43.18 (17) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
45.72 (18) 0.00 0.00 0.00 27.44 0.00 27.44 0.00 0.00 0.00 0.77 0.00 0.77
48.26 (19) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
50.80 (20) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
53.34 (21) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
55.88 (22) 13.58 0.00 0.00 0.00 0.00 13.58 0.58 0.00 0.00 0.00 0.00 0.58
58.42 (23) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
60.96 (24) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
Total 13.58 15.44 2090.24 347.31 203.16 2669.73 0.58 0.01 6.12 1.45 0.76 8.91
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
228
after overstory release (Stromayer and Warren 1997). These factors could be deleterious
to stands of Fir in the Valley. Indeed, Michael (1992) predicted that Red
Spruce would replace Fir in the Valley because Deer seldom browse Spruce.
Adelgids also impacted Fir. Between 2000 and 2002, the Adelgid infestation
rate increased by 17.4%. By 2002, about 69% of the trees were infested. There
was evidence of heavier infestation levels in 2002 than in 2000. From 2000 to
2002, Fir classified as lightly or moderately infested declined, while the proportion
of heavily infested trees rose by 10%. Further, 43% (n = 64) of all trees
measured in 2002 were dead. Therefore, more trees were both heavily infested
and dead in 2002 than in 2000, indicating that a growing proportion of trees were
being impacted by Adelgids. Heavy Adelgid infestation can kill Fir trees within
2–3 years (Hagle et al. 1987, Johnson and Lyon 1988), thus, it is likely that the
mortality we observed was caused by the Adelgids.
The Fir trees that were heavily infested by Adelgids were larger than the trees
with light, moderate, or no infestation. Additionally, dead Firs were larger than
those lightly or not infested. In general, old, large Firs are more susceptible to
Adelgids (Johnson and Lyon 1988). Because larger trees typically produce the
most seeds (Hardin et al. 2001), we conclude that Adelgids are likely reducing
the survival and recruitment of Fir on the Freeland Tract.
Deer and Adelgids are not the only threats to Balsam Fir. Castor canadensis
Kuhl.(North American Beaver, hereafter referred to as “Beaver”) and atmospheric
deposition are also potential threats. Beaver are common throughout the East
and have re-established themselves as pests in some areas by flooding roadways
and timber stands (Muller-Shwarze 1992). Because of their direct and often
significant impact on ecosystem structure and function, Beaver are considered a
keystone species (Gurnell 1998). By building dams and inundating areas, Beaver
kill trees; flooding is a greater threat to Fir than their actual consumption of trees
because Fir and other evergreens are not a desirable food of Beaver (Gurnell
1998, Muller-Shwarze 1992).
It has been suggested that atmospheric deposition causes declines in subalpine
coniferous forests, where the strong acids added to the system can leach
soils of nutrients including calcium (McLaughlin et al. 1990). The atmospheric
input of acid can increase the solubility of aluminum and other toxins, which
plants then take up in excess, compounding the effects of deposition (McLaughlin
et al. 1990). The additional stressors of Beaver and pollutant deposition may
further complicate Fir restoration.
Management Implications
The effects of White-tailed Deer and Balsam Woolly Adelgid need to be considered
in crafting Balsam Fir restoration plans. Of the two, the Adelgid is the
more pressing stressor in the Fir stands on the Freeland tract because trees there
are heavily infested. The Adelgid has some natural insect predators, but most
are not effective in limiting populations (Martineau 1984). Martineau (1984)
indicated that artificial control is difficult because the Adelgid lives under the
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
229
swellings on twigs, where the insect cannot be reached by chemical insecticides.
Although it has been attempted, biological control remains mostly unsuccessful
in stopping the spread of Adelgids (Fowler 1999).
Even if the Adelgid could be controlled, natural regeneration of this stand will
be difficult because of the browsing pressure from Deer. Our exclosure prevented
browsing on trees within it, but the option of fencing the entire stand, or even just
the seedlings until they reach heights above the browse line, may be too costly
and labor-intensive to implement at an ecologically meaningful scale. Fencing
would also exclude Deer from an area they have been using extensively. Reducing
Deer numbers by increasing their harvest may be a more practical solution.
So what does all this mean for Balsam Fir? If managers do nothing to intervene,
these stands will likely be extirpated from the area, and other tree species,
such as Red Spruce, will replace it. Immediate and forceful action is necessary
to conserve Balsam Fir as a viable part of the Valley’s flora. Without intervention,
Balsam Fir may suffer the same fate as Castanea dentata (Marsh.) Borkh.
(American Chestnut) and become extirpated, thereby lowering the overall biodiversity
of the Appalachian landscape.
Acknowledgments
We thank the US Fish and Wildlife Service (CVNWR) for logistical support. We
thank K.K. Sturm, E. Grafton, and D. Washington of the CVNWR for collecting and
sharing data on Adelgids. During the study, J.T. Anderson was supported by the Division
of Forestry and Natural Resources at West Virginia University (WVU) and by the West
Virginia Agricultural and Forestry Experiment Station (McIntire-Stennis). This paper is
based on a series of undergraduate research projects; we thank WVU for the undergraduate
research experience. This is manuscript number 3217 of the WVU’s Agricultural and
Forestry Experiment Station.
Literature Cited
Akins, J.W. 1994. Impacts of clear-cut size on wildlife use and tree regeneration. M.Sc.
Thesis. West Virginia University, Morgantown, WV. 115 pp.
Aldous, S.E. 1944. A deer-browse survey method. Journal of Mammalogy 25:130–136.
Avery, T.E., and H.E. Burkhart. 2002. Forest Measurements. McGraw Hill, New York,
NY. 480 pp.
Bakuzis, E.V., and H.L. Hansen. 1965. Balsam Fir. University of Minnesota Press, Minneapolis,
MN. 468 pp.
Chouinard, A., and L. Filion. 2001. Detrimental effects of White-tailed Deer browsing
on Balsam Fir growth and recruitment in second-growth stand on Anticosti Island,
Quebec. Ecoscience 8:199–210.
Clarkson, R.B. 1964. Tumult on the Mountains. McClain Printing Co., Parsons, WV. 410 pp.
Cody, R.P., and J.K. Smith. 1991. Applied statistics and the SAS programming language,
3rd Edition. Elsevier Scientific Publications, New York, NY. 403 pp.
Core, E.L. 1966. The Vegetation of West Virginia. McClain Printing Co., Parsons, WV.
217 pp.
Doenier, P.B., G.D. DelGiudice, and M.R. Riggs. 1997. Effects of winter supplemental
feeding on browse consumption by White-tailed Deer. Wildlife Society Bulletin
25:235–243.
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
230
Fansler, H.F. 1962. History of Tucker County. McClain Printing Co., Parsons, WV. 702 pp.
Fortney, R.H. 1975. The vegetation of Canaan Valley, West Virginia: A taxonomic and
ecological study. Ph.D. Dissertation. West Virginia University, Morgantown, WV.
208 pp.
Fowler, G.A. 1999. The potential of juvabione as a host-resistance mechanism against
the Balsam Woolly Adelgid, Adelges piceae (Ratzeburg). Ph.D. Dissertation. North
Carolina State University, Raleigh, NC. 118 pp.
Gurnell, A.M. 1998. The hydrogeomorphological effects of Beaver dam-building activity.
Progress in Physical Geography 22:167–189.
Hagle, S.K., S. Tunnock, K.E. Gibson, and C.J. Gilligan. 1987. Field guide to diseases
and insect pests of Idaho and Montana forests. US Department of Agriculture, Missoula,
MT. 123 pp.
Hardin, J.W., J.D. Leopold, and F.M. White. 2001. Textbook of Dendrology, 9th Edition.
McGraw Hill, New York, NY. 544 pp.
Johnson, W.T., and H.H. Lyon. 1988. Insects that Feed on Trees and Shrubs, 2nd Edition.
Cornell University Press, Ithaca, NY. 556 pp.
Jones, W.L. 1984. Christmas-tree damage by White-tailed Deer in West Virginia. M.Sc.
Thesis. West Virginia University, Morgantown, WV. 156 pp.
Langdon, C.A. 2001. A comparison of White-tailed Deer population-estimation methods
in West Virginia. M.Sc. Thesis. West Virginia University, Morgantown, WV. 130 pp.
Leopold, D.J., W.C. McComb, and R.N. Muller. 1998. Trees of the Central Hardwood
Forests of North America: An identification and cultivation guide. Timber Press,
Portland, OR. 469 pp.
Martineau, R. 1984. Insects Harmful to Forest Trees. Multiscience Publications Ltd.,
Laval, Québec, Canada. 261 pp.
McLaughlin, S.B., C.J. Anderson, N.T. Edwards, W.K. Roy, and P.A. Layton. 1990.
Seasonal patterns of photosynthesis and respiration of Red Spruce saplings from
two elevations in declining southern Appalachian stands. Canadian Journal of Forest
Research 20:485–495.
Michael, E.D. 1992. Impact of deer browsing on regeneration of Balsam Fir in Canaan
Valley, West Virginia. Northern Journal of Applied Forestry 9:89–90.
Muller-Shwartze, D. 1992. Beaver waterworks. Natural History 101:52–54.
Neff, D.J. 1968. The pellet-group count technique for big game trend, census, and distribution:
A review. Journal of Wildlife Management 32:598–605.
Ratti, J.T., and E.O. Garton. 1996. Research and experimental design. Pp. 13–14 In T.A.
Bookout (Ed.). Research and management techniques for wildlife and habitats. Allen
Press, Lawrence, KS. 740 pp.
Smith, D.M., B.C. Larson, M.J. Kelty, and P.M. Ashton. 1997. The Practice of Silviculture.
John Wiley and Sons, New York, NY. 560 pp.
Sokal, R.R., and F.J. Rohlf. 1995. Biometry. W.H. Freeman and Company, New York,
NY. 887 pp.
Stephenson, S.L. (Ed.). 1993. Upland Forests of West Virginia. McClain Printing Co.,
Parsons, WV. 295 pp.
Stephenson, S.L., and H.S. Adams. 1986. An ecological study of Balsam Fir communities
in West Virginia. Bulletin of the Torrey Botanical Club 113:372–381.
Stromayer, K.K., and R.J. Warren. 1997. Are overabundant deer herds in the eastern
United States creating alternate stable states in forest plant communities? Wildlife
Society Bulletin 25:227–234.
Southeastern Naturalist
C. Cherefko, C. Fridley, J. Medsger, M. Woody, and J.T. Anderson
2015 Vol. 14, Special Issue 7
231
US Department of Agriculture (USDA). 1967. Soil survey, Tucker County, West Virginia.
US Government Printing Office, Washington, DC. 78 pp.
Warren, K.A. 2001. Habitat use, nest success, and management recommendations for
grassland birds of the Canaan Valley National Wildlife Refuge, West Virginia. M.Sc.
Thesis., West Virginia University, Morgantown, WV. 163 pp.
Weedfall, R.O., and W.H. Dickerson. 1965. The climate of Canaan Valley and Blackwater
Falls State Park, West Virginia. West Virginia University Experiment Station Report
43, Morgantown, WV. 14 pp.
